Yeti ASR TURQ Frame

86765162ab9f1473fed70b2e55f74d35.jpg?VersionId=COdbn9a0LsH7p.JYWlPO4A0

frame spruce.jpg?VersionId=9jZs8cRjEjSJY3pkC3j2ja9eSCBW

86765162ab9f1473fed70b2e55f74d35.jpg?VersionId=mo3QLLUG1a8QvGan

78a2165d111873f69897b0674a756d9a.jpg?VersionId=Fd8o

frame spruce.jpg?VersionId=gc1H5oRNWXxUiYLN

Yeti

Specifications

Product

Yeti ASR TURQ Frame

Intended Use

Cross Country

Trail

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	XS	SM	MD	LG	XL
Top Tube Length	554mm	574mm	600mm	610mm	630mm
Head Tube Angle	66.5°	66.5°	66.5°	66.5°	66.5°
Head Tube Length	92mm	98mm	101mm	111mm	133mm
Seat Tube Angle	75.5°	75.5°	75.5°	75.5°	75.5°
Seat Tube Length	400mm	410mm	430mm	470mm	495mm
Bottom Bracket Height	335mm	335mm	335mm	335mm	335mm
Chainstay Length	433mm	435mm	437mm	439mm	441mm
Wheelbase	1122mm	1144mm	1174mm	1201mm	1236mm
Standover	768mm	768mm	771mm	771mm	776mm
Reach	400mm	420mm	445mm	465mm	490mm
Stack	592mm	592mm	600mm	610mm	630mm
Additional Info	• All specifications listed are with 120mm travel fork with 531mm axle-to-crown length and 44mm offset • Bottom bracket heights are listed as "estimated" by Yeti

Sizes Additional Info

• All specifications listed are with 120mm travel fork with 531mm axle-to-crown length and 44mm offset
• Bottom bracket heights are listed as "estimated" by Yeti

View Full Geometry

Size	XS	SM	MD	LG	XL
Top Tube Length	554mm	574mm	600mm	610mm	630mm
Head Tube Angle	66.5°	66.5°	66.5°	66.5°	66.5°
Head Tube Length	92mm	98mm	101mm	111mm	133mm
Seat Tube Angle	75.5°	75.5°	75.5°	75.5°	75.5°
Seat Tube Length	400mm	410mm	430mm	470mm	495mm
Bottom Bracket Height	335mm	335mm	335mm	335mm	335mm
Chainstay Length	433mm	435mm	437mm	439mm	441mm
Wheelbase	1122mm	1144mm	1174mm	1201mm	1236mm
Standover	768mm	768mm	771mm	771mm	776mm
Reach	400mm	420mm	445mm	465mm	490mm
Stack	592mm	592mm	600mm	610mm	630mm
Additional Info	• All specifications listed are with 120mm travel fork with 531mm axle-to-crown length and 44mm offset • Bottom bracket heights are listed as "estimated" by Yeti

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

TURQ Series carbon fiber front and rear triangles, size-specific tuning; one-piece billet 7075 aluminum alloy SL link; molded chainstay, seatstay, and down tube protection

Rear Travel

115mm

Rear Shock

RockShox SIDLuxe Ultimate, RockShox TwistLoc Ultimate 3-position remote, 190mm length x 40mm stroke

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

73mm English/BSA threaded

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

29" x 2.4"

ISCG Tabs

None

Bottle Cage Mounts

Two inside front triangle

Colors

Turquoise, Greyhound, Spruce Gloss

Warranty

Lifetime frame, 1 year paint and finish

Weight

Without shock: 3 lb 6.7 oz (1,552 g)

With shock: 4 lb 0.5 oz (1,828 g)

Miscellaneous

• 2024-2026 version
• Single pivot flexstays rear suspension design
• Internal cable routing with configurable cable ports
• SRAM UDH (Universal Derailleur Hanger)
• Integrated rear frame fender
• Optional integrated pivot-mounted upper slider chainguide available
• Designed for 120mm travel forks; compatible with up to 140mm travel forks with 555mm max axle-to-crown length
• 160mm rear brake tabs; 180mm max rear rotor
• 28 tooth minimum chainring; 36 tooth (XS/SM) or 38 tooth (MD-XL) max chainring

Price

$4,000.00
