Specifications

Product

Pivot Trailcat SL Frame

Intended Use

Cross Country

Trail

Rider

Unisex

Sizes and Geometry

XS (Low, High)

SM (Low, High)

MD (Low, High)

LG (Low, High)

XL (Low, High)

View Full Geometry

Size	XS (Low, High)	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	569mm, 567mm	596mm, 595mm	629mm, 627mm	646mm, 645mm	660mm, 658mm
Head Tube Angle	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°
Head Tube Length	85mm	95mm	107mm	112mm	125mm
Seat Tube Angle	76.0°, 76.4°	76.0°, 76.4°	76.0°, 76.4°	76.0°, 76.4°	76.5°, 76.8°
Seat Tube Length	343mm	368mm	394mm	432mm	470mm
Bottom Bracket Height	338mm (36mm drop), 344mm (30mm drop)	338mm (36mm drop), 344mm (30mm drop)	338mm (36mm drop), 345mm (29mm drop)	338mm (36mm drop), 345mm (29mm drop)	338mm (36mm drop), 345mm (29mm drop)
Chainstay Length	431mm, 429mm	431mm, 429mm	431mm, 429mm	432mm, 430mm	434mm, 432mm
Wheelbase	1143mm, 1142mm	1172mm, 1171mm	1207mm, 1206mm	1226mm, 1225mm	1253mm, 1252mm
Standover	653mm, 657mm	674mm, 678mm	678mm, 682mm	692mm, 696mm	707mm, 712mm
Reach	410mm, 415mm	435mm, 440mm	465mm, 470mm	480mm, 485mm	500mm, 505mm
Stack	604mm, 601mm	614mm, 610mm	625mm, 621mm	629mm, 625mm	641mm, 637mm
Additional Info	• Geometry adjustable via two-position flip chip in upper linkage • All specifications listed are with 29" wheels front/rear and 140mm travel fork with 44mm offset

Sizes Additional Info

• Geometry adjustable via two-position flip chip in upper linkage
• All specifications listed are with 29" wheels front/rear and 140mm travel fork with 44mm offset

View Full Geometry

Size	XS (Low, High)	SM (Low, High)	MD (Low, High)	LG (Low, High)	XL (Low, High)
Top Tube Length	569mm, 567mm	596mm, 595mm	629mm, 627mm	646mm, 645mm	660mm, 658mm
Head Tube Angle	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°	65.8°, 66.3°
Head Tube Length	85mm	95mm	107mm	112mm	125mm
Seat Tube Angle	76.0°, 76.4°	76.0°, 76.4°	76.0°, 76.4°	76.0°, 76.4°	76.5°, 76.8°
Seat Tube Length	343mm	368mm	394mm	432mm	470mm
Bottom Bracket Height	338mm (36mm drop), 344mm (30mm drop)	338mm (36mm drop), 344mm (30mm drop)	338mm (36mm drop), 345mm (29mm drop)	338mm (36mm drop), 345mm (29mm drop)	338mm (36mm drop), 345mm (29mm drop)
Chainstay Length	431mm, 429mm	431mm, 429mm	431mm, 429mm	432mm, 430mm	434mm, 432mm
Wheelbase	1143mm, 1142mm	1172mm, 1171mm	1207mm, 1206mm	1226mm, 1225mm	1253mm, 1252mm
Standover	653mm, 657mm	674mm, 678mm	678mm, 682mm	692mm, 696mm	707mm, 712mm
Reach	410mm, 415mm	435mm, 440mm	465mm, 470mm	480mm, 485mm	500mm, 505mm
Stack	604mm, 601mm	614mm, 610mm	625mm, 621mm	629mm, 625mm	641mm, 637mm
Additional Info	• Geometry adjustable via two-position flip chip in upper linkage • All specifications listed are with 29" wheels front/rear and 140mm travel fork with 44mm offset

Wheel Size

29"

27.5+

Mixed Wheel Size

Frame Material

Carbon Fiber

Frame Material Details

Hollow Core carbon fiber front and rear triangles; molded seatstay, chainstay, and lower down tube protection

Rear Travel

120mm

Rear Shock

FOX FLOAT Factory, Kashima coating, trunnion mount, 165mm length x 45mm stroke

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

92mm press-fit

Rear Dropout / Hub Dimensions

12mm x 157mm (SuperBoost+)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

2.6"

ISCG Tabs

ISCG05

Bottle Cage Mounts

One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System

Colors

Green Meadow Mist, Doctor Purple

Warranty

Lifetime frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings

Weight

5 lb 5.7 oz (2,430 g)

Miscellaneous

• 2025 version
• dw-link rear suspension design
• Geometry adjustable via two-position flip chip in upper linkage
• Compatible with 27.5+ wheels or mixed ("Mullet") setups (29" front, 27.5" rear)
• Toolshed in-frame downtube storage system; includes two custom storage bags
• Internal cable routing with Dual Cable Port design
• SRAM UDH (Universal Derailleur Hanger)
• Designed for 140mm travel forks with 44mm offset
• Post-style rear brake mounts
• Weight listed without shock
• Includes headset: Pivot Precision, sealed cartridge bearings

Price

$4,399.00

More Info

Pivot website
