Yeti

Specifications

Product

Yeti SB120 TURQ Frame

Intended Use

Cross Country

Trail

Rider

Unisex

Sizes and Geometry

XXL

View Full Geometry

Size	XS	SM	MD	LG	XL	XXL
Top Tube Length	540mm	571mm	603mm	625mm	652mm	672mm
Head Tube Angle	66.5°	66.5°	66.5°	66.5°	66.5°	66.5°
Head Tube Length	92mm	98mm	104mm	115mm	126mm	147mm
Seat Tube Angle	76.5°	76.5°	76.5°	76.5°	76.5°	76.5°
Seat Tube Length	345mm	365mm	400mm	440mm	470mm	485mm
Bottom Bracket Height	335mm	335mm	335mm	335mm	335mm	335mm
Chainstay Length	433mm	435mm	437mm	439mm	441mm	443mm
Wheelbase	1122mm	1157mm	1191mm	1217mm	1249mm	1274mm
Standover	699mm	709mm	714mm	718mm	720mm	725mm
Reach	395mm	425mm	455mm	475mm	500mm	515mm
Stack	604mm	610mm	615mm	625mm	635mm	655mm
Additional Info	• All specifications listed are with 130mm travel fork with 544mm axle-to-crown length and 44mm offset. • Bottom bracket heights are listed as "estimated" by Yeti.

Sizes Additional Info

• All specifications listed are with 130mm travel fork with 544mm axle-to-crown length and 44mm offset.
• Bottom bracket heights are listed as "estimated" by Yeti.

View Full Geometry

Size	XS	SM	MD	LG	XL	XXL
Top Tube Length	540mm	571mm	603mm	625mm	652mm	672mm
Head Tube Angle	66.5°	66.5°	66.5°	66.5°	66.5°	66.5°
Head Tube Length	92mm	98mm	104mm	115mm	126mm	147mm
Seat Tube Angle	76.5°	76.5°	76.5°	76.5°	76.5°	76.5°
Seat Tube Length	345mm	365mm	400mm	440mm	470mm	485mm
Bottom Bracket Height	335mm	335mm	335mm	335mm	335mm	335mm
Chainstay Length	433mm	435mm	437mm	439mm	441mm	443mm
Wheelbase	1122mm	1157mm	1191mm	1217mm	1249mm	1274mm
Standover	699mm	709mm	714mm	718mm	720mm	725mm
Reach	395mm	425mm	455mm	475mm	500mm	515mm
Stack	604mm	610mm	615mm	625mm	635mm	655mm
Additional Info	• All specifications listed are with 130mm travel fork with 544mm axle-to-crown length and 44mm offset. • Bottom bracket heights are listed as "estimated" by Yeti.

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

TURQ Series carbon fiber front and rear triangles; molded chainstay, seatstay, and down tube protection

Rear Travel

120mm

Rear Shock

FOX FLOAT DPS Factory, Kashima coating, custom tune, 190mm length x 45mm stroke

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

73mm English/BSA threaded

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

29" x 2.6"

ISCG Tabs

ISCG05

Bottle Cage Mounts

One inside front triangle

Colors

2025-2026: Turquoise, Lichen, Raw Carbon
2023-2024: Turquoise, Dust, Loch, Raw Carbon

Warranty

Lifetime frame and Switch Infinity Link, 1 year paint and finish

Weight

6 lb 10.6 oz (3,021 g)

Miscellaneous

• 2023-2026 version
• Switch Infinity V2 rear suspension design
• Internally tunneled cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Designed for 130mm travel forks; 150mm max travel (564mm axle-to-crown length)
• 180mm post-mount rear brake tabs; 203mm max rotor
• Max chainring size: 32 tooth (oval), 34 tooth (round)

Price

$4,300.00
