Specifications

Product

Trek Supercaliber SLR Gen 2 Frame

Intended Use

Cross Country

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	SM	MD	ML	LG	XL
Top Tube Length	571mm	592mm	605mm	622mm	663mm
Head Tube Angle	67.5°	67.5°	67.5°	67.5°	67.5°
Head Tube Length	90mm	90mm	90mm	100mm	125mm
Seat Tube Angle	74.5°	74.5°	74.5°	74.5°	74.5°
Seat Tube Length	395mm	420mm	440mm	460mm	525mm
Bottom Bracket Height	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)
Chainstay Length	435mm	435mm	435mm	435mm	435mm
Wheelbase	1113mm	1138mm	1153mm	1172mm	1217mm
Standover	760mm	772mm	772mm	772mm	772mm
Reach	410mm	435mm	450mm	465mm	500mm
Stack	590mm	590mm	590mm	599mm	622mm
Additional Info	All specifications listed are with 110mm travel fork with 43mm offset for a trail value of 109mm (all sizes)

Sizes Additional Info

All specifications listed are with 110mm travel fork with 43mm offset for a trail value of 109mm (all sizes)

View Full Geometry

Size	SM	MD	ML	LG	XL
Top Tube Length	571mm	592mm	605mm	622mm	663mm
Head Tube Angle	67.5°	67.5°	67.5°	67.5°	67.5°
Head Tube Length	90mm	90mm	90mm	100mm	125mm
Seat Tube Angle	74.5°	74.5°	74.5°	74.5°	74.5°
Seat Tube Length	395mm	420mm	440mm	460mm	525mm
Bottom Bracket Height	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)	327mm (46mm drop)
Chainstay Length	435mm	435mm	435mm	435mm	435mm
Wheelbase	1113mm	1138mm	1153mm	1172mm	1217mm
Standover	760mm	772mm	772mm	772mm	772mm
Reach	410mm	435mm	450mm	465mm	500mm
Stack	590mm	590mm	590mm	599mm	622mm
Additional Info	All specifications listed are with 110mm travel fork with 43mm offset for a trail value of 109mm (all sizes)

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

SLR OCLV Mountain Carbon high modulus layup front triangle, OCLV Mountain Carbon rear triangle, molded chainstay protection, 3M adhesive film on the underside of the downtube

Rear Travel

80mm

Rear Shock

RockShox SIDLuxe Trek IsoStrut

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

92mm PressFit

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

29" x 2.4"

ISCG Tabs

None

Bottle Cage Mounts

Two inside front triangle

Colors

Carbon Red Smoke, Deep Smoke

Warranty

Lifetime frame; 2 years rear suspension linkage components, Trek/Bontrager parts, and paint/decals

Weight

4 lb 4.8 oz (1,950 g)

Miscellaneous

• 2024-2026 Gen 2 version
• IsoStrut rear suspension design with pivotless seat stays
• Internal cable routing; includes lightweight foam cable tubing
• SRAM UDH (Universal Derailleur Hanger)
• Weight given for size MD
• 120mm max fork travel (533mm axle-to-crown length); designed for 110mm travel forks
• 30-38 tooth chainring compatibility
• 160mm max rear brake rotor
• Includes headset: FSA IS-2

Price

$4,399.99
