Specifications

Product Privateer 141 Frame
Riding Type Enduro / All-Mountain, Trail
Rider Unisex
Sizes and Geometry
P1, P2, P3, P4 View Geometry
Size P1 P2 P3 P4
Top Tube Length 559mm 590mm 612mm 639mm
Head Tube Angle 64.5° 64.5° 64.5° 64.5°
Head Tube Length 130mm 120mm 130mm 140mm
Seat Tube Angle 78.88° 78.76° 78.72° 78.67°
Seat Tube Length 400mm 420mm 450mm 480mm
Bottom Bracket Height 15mm (drop) 30mm (drop) 30mm (drop) 30mm (drop)
Chainstay Length 434mm 440mm 446mm 452mm
Wheelbase 1197mm 1236mm 1266mm 1301mm
Standover
Reach 440mm 465mm 485mm 510mm
Stack 607mm 628mm 637mm 646mm
* Additional Info P1 takes 27.5" wheels; P2/P3/P4 take 29" wheels
Wheel Size 27.5" (650b), 29"
Frame Material Aluminum
Frame Material Details 6066-T6 alloy
Rear Travel 141mm
Rear Shock Custom FOX DPX2 Performance Elite, 205mm x 57.5mm, Trunnion upper mount, 8x30mm lower mount
Head Tube Diameter Tapered (ZS44/ZS56)
Bottom Bracket 73mm threaded
Rear Dropout / Hub Dimensions 148mm x 12mm Boost
Front Derailleur Size
Seatpost Diameter 31.6mm
Max Tire Size 27.5"/29”x2.6"
ISCG Tabs ISCG 05
Bottle Cage Mounts Yes (single)
Colors Charcoal Grey, Heritage Green, Satin Raw
Warranty 5 years frame
Weight 8 lb 2.4 oz (3,697 g)
Miscellaneous 2021 model year
Seat clamp, axle, and sealed cartridge bearing headset included
Size P1 takes 27.5" wheels; Size P2-P4 take 29" wheels
Max chainring size: Boost/3mm offset 34 tooth
Chainline: 52mm, minimum 168mm Q-factor
Approximate frame weight listed is for a size P1 without shock, axle, etc.
Compatible with both coil and air shocks
Headtube cable guides stop cable rub and keep rattling to a minimum
3 bearings in main pivot
One-piece rocker link
