2012 Trek Top Fuel 9.8 Bike (discontinued)

Views:

Discontinued

Trek

Edit Tags Done

Create New Tag

Error

Edit Tags Done

Where To Buy
	Free standard shipping on all bikes (contiguous U.S. only). Flat rate shipping to Hawaii and Alaska.	$6,549.99	Buy it
	Free shipping on orders of $99 or more (U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Buy direct from the manufacturer	No match. Browse other Mountain Bikes
	Free U.S. shipping on orders over $45. International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on complete bike purchases (continental U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping and free 100-day returns on all U.S. orders. Shipping available to North America, Canada, and Europe (including Switzerland).	No match. Browse other Mountain Bikes
	Free standard shipping on orders over $49.	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Shipping available to Alaska, Hawaii, Guam, Virgin Islands, and Puerto Rico.	No match. Browse other Mountain Bikes
	Free standard shipping on orders of $50 or more (U.S. only). International shipping available. Free on orders of $150 or more. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping and free returns on orders of $50 or more (continental U.S. only)	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $50 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $60 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping on orders over $50 (U.S. only).	No match. Browse other Mountain Bikes
Show more choices

Where To Buy
	Free standard shipping on all bikes (contiguous U.S. only). Flat rate shipping to Hawaii and Alaska.
	Top Fuel 9.8 XT	$6,549.99	Buy it
	Top Fuel 9.8 GX	$7,049.99	Buy it
	Top Fuel 9.8 GX AXS	$7,549.99	Buy it
	Free shipping on orders of $99 or more (U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Buy direct from the manufacturer	No match. Browse other Mountain Bikes
	Free U.S. shipping on orders over $45. International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on complete bike purchases (continental U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping and free 100-day returns on all U.S. orders. Shipping available to North America, Canada, and Europe (including Switzerland).	No match. Browse other Mountain Bikes
	Free standard shipping on orders over $49.	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Shipping available to Alaska, Hawaii, Guam, Virgin Islands, and Puerto Rico.	No match. Browse other Mountain Bikes
	Free standard shipping on orders of $50 or more (U.S. only). International shipping available. Free on orders of $150 or more. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping and free returns on orders of $50 or more (continental U.S. only)	No match. Browse other Mountain Bikes
	Free shipping on orders over $75 (contiguous U.S. only). Free international shipping available with minimum order values. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $50 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free shipping on orders over $60 (contiguous U.S. only). International shipping available. Some exclusions apply.	No match. Browse other Mountain Bikes
	Free ground shipping on orders over $50 (U.S. only).	No match. Browse other Mountain Bikes
Show less choices

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product

Trek Top Fuel 9.8 Bike

Model Year

2012

Riding Type

Cross Country

Rider

Unisex

Sizes and Geometry

15.5, 17.5, 18.5, 19.5, 21.5 View Geometry

Size	15.5	17.5	18.5	19.5	21.5
Top Tube Length	21.6	23	23.8	24.6	25.2
Head Tube Angle	70°	70°	70°	70°	70°
Head Tube Length	4.1	5.1	5.5	5.9	6.7
Seat Tube Angle	73.5	73.5	73.5	73.5	73.5
Seat Tube Length	15.5	17.5	18.5	19.5	21.5
Bottom Bracket Height	12.9	12.9	12.9	12.9	12.9
Chainstay Length	16.8	16.8	16.8	16.8	16.8
Wheelbase	41.4	43	43.8	44.6	45.3
Standover	28.3	28.6	28.7	28.9	29.6
Reach
Stack

Wheel Size

Frame Material

Carbon Fiber

Frame Material Details

OCLV Carbon Fiber

Rear Travel

100mm

Rear Shock

Fox Performance Series Float RP-2 BSD w/remote ProPedal, rebound; 6.5x1.5", tuned by Trek in California

Fork

Fox Evolution Series 32 Float RL, air spring, remote lockout, rebound, E2 tapered steerer, 15QR thru axle, 100m travel

Fork Travel

100mm

Head Tube Diameter

1.5 Taper

Headset

Cane Creek IS-3, E2, alloy cartridge

Handlebar

Bontrager Race X Lite Carbon Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Stem

Bontrager Race Lite, 31.8mm

Grips

Bontrager Race Lite, single lock-on

Brakes

Shimano SLX M666 hydraulic disc brakes

Brake Levers

Shimano SLX M666 hydraulic disc brakes

Drivetrain

Shifters

Shimano SLX M660-10, 10 speed

Front Derailleur

Shimano SLX

Rear Derailleur

Shimano Deore XT M780 Shadow

ISCG Tabs

Chainguide

Cranks

Shimano Deore XT M785, 40/28

Chainrings

40/28

Bottom Bracket

Pedals

Chain

Cassette

Shimano SLX HG81-10 11-36, 10 speed

Rims

Bontrager Race Lite Pro TLR Disc wheel system Tubeless Ready

Hubs

15mm front hub, 135x5mm rear hub, 28 hole, center lock,

Spokes

Tires

Bontrager XR1 Expert, 26x2.0"

Saddle

Bontrager Evoke 2, chromoly rails

Seatpost

Bontrager Race XXX Lite, 34.0mm, 5mm offset

Seatpost Diameter

34mm

Seatpost Clamp

Rear Dropout / Hub Dimensions

135x5

Max. Tire Size

Bottle Cage Mounts

Colors

Onyx Carbon/Paramount Grey

Warranty

Weight

N/A

Miscellaneous

Price

$5,249.99
