Specifications

Product
Trek Supercaliber SL 9.7 GX AXS T-Type Gen 2 Bike
Model Year
2025
Riding Type
Cross Country
Rider
Unisex
Sizes and Geometry
SM
MD
ML
LG
XL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
SL OCLV Mountain Carbon front triangle, OCLV Mountain Carbon rear triangle, molded chainstay protection, 3M adhesive film on the underside of the downtube
Rear Travel
80mm
Rear Shock
RockShox SIDLuxe Trek IsoStrut, 2-position dual remote lockout
Fork
RockShox SID, DebonAir spring, Rush RL damper, 2-position dual remote lockout, 44mm offset, 35mm stanchions, Maxle Stealth thru-axle
Fork Travel
110mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
FSA IS-2
Handlebar
SM: Bontrager Kovee Pro, OCLV Carbon, 720mm width, 5mm rise, 35mm clamp diameter
MD-XL: SM: Bontrager Line Pro, OCLV Carbon, 750mm width, 15mm rise, 35mm clamp diameter
Stem
Bontrager Elite, 13° rise, 35mm bar clamp
Length: 60mm (SM/MD), 70mm (ML), 80mm (LG), 90mm (XL)
Grips
Foam
Brakes
SRAM Level Bronze, 4-piston, SRAM CenterLine 6-bolt rotors (180mm front, 160mm rear) with round edges
Brake Levers
SRAM Level Bronze Stealth, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM GX Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
None
Chainguide
None
Cranks
SRAM GX Eagle Transmission Alloy DUB
Length: 170mm (SM-ML), 175mm (LG/XL)
Chainrings
SRAM GX Eagle Transmission, 34 tooth
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM GX Eagle Transmission Flattop, 12-speed
Cassette
SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth
Rims
Bontrager Kovee Comp 25, alloy, tubeless ready
Hubs
Bontrager Kovee Comp wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with Rapid Drive 108 freehub and XD driver
Spokes
Bontrager Kovee Comp wheelset
Tires
Bontrager Sainte-Anne RSL XR, dual compound, aramid bead, 220 TPI, tubeless ready, 29" x 2.4"
Saddle
Bontrager Verse Short Elite, hollow magnesium rails, 145mm width
Seatpost
Bontrager Line dropper, MaxFlow
Drop: 100mm (SM), 150mm (MD-LG), 170mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.4"
Bottle Cage Mounts
Two inside front triangle
Colors
Red Carbon Smoke
Warranty
Lifetime frame; 2 years rear suspension linkage components, Trek/Bontrager parts, and paint/decals
Weight
26 lb 3.1 oz (11880 g)
Miscellaneous
• IsoStrut rear suspension design with pivotless seat stays
• Internal cable routing with internal guide tubes
• SRAM UDH (Universal Derailleur Hanger)
• Includes Bontrager TLR tubeless rim strips, valve stems, and sealant
• Includes SRAM AXS battery charger
• Weight given for size MD set up tubeless
Price
$5,699.99
