2026 Trek Fuel EX 5 Gen 7 Bike

• ABP (Active Braking Pivot) rear suspension design
• SM has mixed ("Mullet") wheels (29" front, 27.5" rear); MD-XL have 29" wheels front/rear
• Internal frame storage compartment in down tube; includes custom storage bag
• Guided internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Includes Bontrager TLR tubeless rim strips, valve stems, and sealant
• Weight given for size MD set up tubeless
• Frame weight: 4.95 kg (10.92 lbs)

Rear suspension leverage rate adjustable via flip chip at lower shock mount:
• Less progressive setting intended for a plusher feel perfect for rugged trails with square-edge bumps
• More progressive setting intended for hitting big features without bottom-out, or to run a coil shock

Interchangeable alloy rocker link and lower shock mount allow three possible configurations:
• EX setup (default for this build) has 29" wheels (size SM has 27.5" rear wheel), 145mm rear travel, and 150mm front travel, for do-it-all balanced trail bike handling
• MX setup has mixed ("Mullet") wheels (29" front, 27.5" rear), 150mm rear travel, and 160mm front travel, for more playful and poppy handling
• LX setup has 29" wheels, 160mm rear travel, and 170mm front travel, for big hits and steep terrain on enduro-style rides
