Specifications

Product

Orbea Alma M Pro Bike

Model Year

2024

Intended Use

Cross Country

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	559mm	593mm	618mm	647mm
Head Tube Angle	68°	68°	68°	68°
Head Tube Length	90mm	100mm	110mm	125mm
Seat Tube Angle	74.5°	74.5°	74.5°	74.5°
Seat Tube Length	400mm	445mm	483mm	533mm
Bottom Bracket Height	309mm (61mm drop)	309mm (61mm drop)	309mm (61mm drop)	309mm (61mm drop)
Chainstay Length	430mm	430mm	430mm	430mm
Wheelbase	1083mm	1118mm	1144mm	1175mm
Standover	693mm	729mm	749mm	819mm
Reach	395mm	426mm	448mm	474mm
Stack	593mm	602mm	612mm	625mm
Additional Info	All specifications listed are with 100mm travel fork with 500.8mm axle-to-crown length and 44mm offset

Sizes Additional Info

All specifications listed are with 100mm travel fork with 500.8mm axle-to-crown length and 44mm offset

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	559mm	593mm	618mm	647mm
Head Tube Angle	68°	68°	68°	68°
Head Tube Length	90mm	100mm	110mm	125mm
Seat Tube Angle	74.5°	74.5°	74.5°	74.5°
Seat Tube Length	400mm	445mm	483mm	533mm
Bottom Bracket Height	309mm (61mm drop)	309mm (61mm drop)	309mm (61mm drop)	309mm (61mm drop)
Chainstay Length	430mm	430mm	430mm	430mm
Wheelbase	1083mm	1118mm	1144mm	1175mm
Standover	693mm	729mm	749mm	819mm
Reach	395mm	426mm	448mm	474mm
Stack	593mm	602mm	612mm	625mm
Additional Info	All specifications listed are with 100mm travel fork with 500.8mm axle-to-crown length and 44mm offset

Wheel Size

29"

Frame Material

Carbon Fiber

Frame Material Details

OMX monocoque high-modulus carbon, molded chainstay protection

Rear Travel

Hardtail

Rear Shock

None

Fork

FOX FLOAT 32 Step-Cast (SC) Factory, FIT4 damper, Kashima coating, FOX 2-position remote lockout
Option: Orbea Spirit Rigid Carbon

Fork Travel

100mm

Head Tube Diameter

Straight

Headset

ACROS Block Lock, semi-integrated, 164° rotation limiter

Handlebar

Orbea Mountain Performance MP10 Carbon, 760mm width, 9° sweep

Stem

Orbea Mountain Performance MP20, 8° drop
Length: 60mm (SM), 75mm (MD/LG), 90mm (XL)

Grips

Silicone foam, slip-on

Brakes

SRAM Level Silver, 2-piston
Option: Shimano XTR M9100, 2-piston

Brake Levers

SRAM Level Silver
Option: Shimano XTR M9100

Drivetrain

Shifters

SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless

Front Derailleur

None

Rear Derailleur

SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless

ISCG Tabs

None

Chainguide

Orbea Alma Carbon OMR/OMX bolt-on guide

Cranks

SRAM X0 Eagle Transmission Alloy DUB
Length: 170mm (SM), 175mm (MD-XL)

Chainrings

SRAM X0 Eagle Transmission, 34 tooth

Bottom Bracket

SRAM DUB, PF92 PressFit

Pedals

None

Chain

SRAM GX Eagle Transmission, 12-speed

Cassette

SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth

Rims

OQUO Mountain Performance MP30TEAM Carbon, 30mm inner width
Option: OQUO Mountain Performance MP30LTD Carbon

Hubs

OQUO Mountain Performance MP30TEAM wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver

Spokes

OQUO Mountain Performance MP30TEAM wheelset

Tires

Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4" WT

Saddle

Selle Italia SLR Boost Fill, titanium rails
Option: Selle Italia SLR Boost SuperFlow Women's

Seatpost

OC Performance XP10 Carbon, zero setback
Option: OC Mountain Control MC20 dropper, 80mm drop

Seatpost Diameter

27.2mm

Seatpost Clamp

Single bolt, 31.2mm

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

29" x 2.4"

Bottle Cage Mounts

Two inside front triangle

Colors

Digital Lavender/Carbon Raw, Wine Red Carbon View/Carbon Raw, Infinity Green Carbon View/Titanium; customizable via Orbea's MyO program

Warranty

Lifetime frame, 3 years paint and finish

Weight

Miscellaneous

• ICR (Internal Cable Routing)
• SRAM UDH (Universal Derailleur Hanger)
• Frame weight: 830g (size MD)
• Includes SRAM AXS Powerpack battery charger

Price

$5,999.00
