Orange Five Frame

Views:
Orange Five Frame
 Orange Five Frame  Orange Five Frame
Create New Tag

Compare to other Frames

Need more info? View our Enduro / All-Mountain Mountain Bike Frames or Trail Mountain Bike Frames buyer's guides.

Specifications

Product Orange Five Frame
Riding Type Enduro / All-Mountain, Trail
Rider Unisex
Sizes and Geometry
S, M, L, XL, XXL View Geometry
Size S M L XL XXL
Top Tube Length 600 620 640 660 680
Head Tube Angle 65° 65° 65° 65° 65°
Head Tube Length 100 110 110 125 130
Seat Tube Angle 74° 74° 74° 74° 74°
Seat Tube Length 15'' 17'' 18'' 19'' 20''
Bottom Bracket Height 329mm (25mm drop) 329mm (25mm drop) 329mm (25mm drop) 329mm (25mm drop) 329mm (25mm drop)
Chainstay Length 433 433 433 433 433
Wheelbase 1176 1197 1217 1240 1261
Standover 695 717 743 768 782
Reach 429 447 467 483 502
Stack 599 608 608 621 626
* Additional Info All measurements are in mm unless otherwise noted
Wheel Size 27.5" (650b)
Frame Material Aluminum
Frame Material Details Monocoque 6061 T6 custom formed aluminum
Rear Travel 145mm
Rear Shock FOX Float DPS Performance, 210x55mm
Upgrade option: RockShox Super Deluxe Ultimate, 210x55mm (£150.00)
Upgrade option: FOX Float DPX2 Factory, 210x55mm (£250.00)
Head Tube Diameter Straight, 49mm
Bottom Bracket 73mm shell, threaded
Rear Dropout / Hub Dimensions 148x12mm
Front Derailleur Size N/A
Seatpost Diameter 30.9mm
Max Tire Size 27.5x2.6''
ISCG Tabs Yes
Bottle Cage Mounts Yes
Colors Fizzy Orange, Cosmic White, Cyan Blue, Norlando Grey, Matte Wasabi Green, Matte Charcoal Grey
Decal options: Black/Grey, Orange/Black, Black/Orange
Warranty 5 year frame warranty
Weight N/A
Miscellaneous 2019-2020 version
Designed and built in Britain
Single-pivot suspension
Internal cable routing
Generation: MK12

Additional accessory options:
- Full-suspension derailleur hanger (£15.00)
- Multi-use Correx plastic bike box (£40.00)
- Orange RideGuard fender (£7.50)
- Orange shock pump (£15.00
Price N/A
More Info

​Base price before upgrades: £2000.00
