Niner AIR 9 RDO Frame

Views:
Niner AIR 9 RDO frame in Blue
Related: Niner
Niner
Edit Tags Done
Create New Tag
Edit Tags Done

Compare to other Frames

Need more info? View our Cross Country Mountain Bike Frames or Trail Mountain Bike Frames buyer's guides.

Specifications
Product Niner AIR 9 RDO Frame
Riding Type Cross Country, Trail
Rider Unisex
Sizes and Geometry
XS, S, M, L, XL View Geometry
Size XS S M L XL
Top Tube Length 575 590 610 630 650
Head Tube Angle 70° 70° 70° 70° 70°
Head Tube Length 95 100 110 120 130
Seat Tube Angle 73° 73° 73° 73° 73°
Seat Tube Length 356 394 419 483 533
Bottom Bracket Height 58mm drop 58mm drop 58mm drop 58mm drop 58mm drop
Chainstay Length 431 431 431 431 431
Wheelbase 1074 1090 1110 1131 1151
Standover 677 714 737 786 832
Reach 393 406 424 441 458
Stack 602 607 617 626 635
* Additional Info All dimensions in mm unless noted otherwise. Geometry based on 100mm travel 51mm offset fork.
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details Race Day Optimized carbon fiber with full length internal cable guides, di2 compatibility, integrated titanium frame guards, and optional eccentric bottom bracket
Rear Travel Hardtail
Rear Shock None
Head Tube Diameter Tapered 1.125-1.5", integrated (SHIS IS42/IS52)
Bottom Bracket 73mm PF30 (optional BioCentric eccentric bottom bracket)
Rear Dropout / Hub Dimensions 148x12mm Boost (M12X1.75PX182L axle)
Front Derailleur Size 34.9mm Side Swing Front Pull
Seatpost Diameter 27.2mm
Max Tire Size 29x2.4"
ISCG Tabs None
Bottle Cage Mounts Yes (two bottles on all sizes)
Colors Orange, Blue, and CMYK
Warranty 5 years
Weight N/A
Miscellaneous - 2019-2020 version
- Designed for 100-120mm travel forks
- Compatible with 1x, 2x, and 3x drivetrains
- 168mm Q-factor
- 180mm maximum rear rotor
- 31.8mm bolt-on seat clamp
Price $2,000
