2013 Pivot Mach 4 X0 (discontinued)

Views:
Discontinued
bike - Pivot MACH 4 (Blue with Sram X9)
2013 Pivot Mach 4 X0 2013 Pivot Mach 4 X0 2013 Pivot Mach 4 X0 2013 Pivot Mach 4 X0
Related: Pivot
Pivot
Edit Tags Done
Create New Tag
Edit Tags Done

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications
Product Pivot Mach 4 X0
Model Year 2013
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
XXS, XS, S, M, L, XL View Geometry
Size XXS XS S M L XL
Top Tube Length 20.8 22.25 22.75 23.25 24 24.6
Head Tube Angle 68.5° 68.7° 69.2° 69.2° 69.7° 69.7°
Head Tube Length 3.5 4 4.25 4.5 5.5 6.1
Seat Tube Angle 72.7° 72.2° 71.7° 71.7° 71.7° 71.7°
Seat Tube Length 14.25 15.75 17.2 18.5 20 21.5
Bottom Bracket Height 13.2 13.17 13.17 13.17 13.17 13.17
Chainstay Length 16.75 16.75 16.75 16.75 16.75 16.75
Wheelbase 41.07 42.33 42.43 42.94 43.74 44.36
Standover 25.9 26.9 28.9 29.15 29.15 29.9
Reach 14.4 15.59 15.78 16.21 16.66 17.08
Stack 20.71 21.23 21.57 21.81 22.76 23.33
Wheel Size
Frame Material Aluminum
Frame Material Details
Rear Travel 100mm
Rear Shock Fox Float CTD Kashima
Fork Fox F120 Fit CTD Trail Adjust Kashima
Fork Travel 120mm
Head Tube Diameter 1.5" Tapered Zero Stack
Headset Pivot Precision Sealed Bearing
Handlebar FSA SL-K Carbon Riser 740mm
Stem FSA SL-K
Grips Pivot Lock On
Brakes Sram X0 Trail
Brake Levers Sram X0
Drivetrain
Shifters Sram X0
Front Derailleur Shimano XT E-Type
Rear Derailleur Sram X0 10-Speed Type 2
ISCG Tabs
Chainguide
Cranks Sram X0 GXP
Chainrings 24/38 Tooth
Bottom Bracket Sram GXP, Press Fit 92mm Wide
Pedals N/A
Chain
Cassette XT M770 11-36 Tooth 10-Speed
Rims DT Tricon 1700 Wheels
Hubs DT Tricon 1700 Wheels
Spokes DT Tricon 1700 Wheels
Tires Kenda Slant 6 R Nevegal F 2.1"
Saddle WTB Volt Race
Seatpost FSA SL-K Carbon
Seatpost Diameter 30.9mm
Seatpost Clamp
Rear Dropout / Hub Dimensions 142mm x 12mm
Max. Tire Size
Bottle Cage Mounts Yes
Colors Anodized Jet Black, Anodized Cobalt Blue, Alpine White with Blue/Black Decals, or Alpine White/Pink (Women’s)
Warranty
Weight N/A
Miscellaneous
Price $5,599
More Info Pivot website
