2022 KHS 7500 Bike
(discontinued)

Discontinued
s1600 photo 487154.jpg?VersionId=v
c70 photo 487154
s1600 photo 487154.jpg?VersionId=v
Related:
KHS
Where To Buy
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
$359.00
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
KHS 7500 Bike
Model Year
2022
Intended Use
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info
SM has 27.5" wheels, MD-XL have 29" wheels.
View Full Geometry
Wheel Size
29"
27.5" (650b)
Frame Material
Aluminum
Frame Material Details
6061 alloy, double-butted custom-formed top tube and down tube
Rear Travel
150mm
Rear Shock
FOX FLOAT DPX2 Performance, EVOL LV, 3-position lever, trunnion mount
Fork
FOX FLOAT 36 Performance, EVOL, GRIP damper, 3-position lever, rebound adjust
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
FSA Orbit 1.5E, zero stack
Handlebar
FSA Grid, 800mm width, 20mm rise, 35mm clamp diameter
Stem
FSA Grid, 3D forged alloy, 35mm bar clamp
Grips
Q2, lock-on
Brakes
Shimano Deore M6120, 4-piston, Shimano RT64 CENTER LOCK rotors (180mm front, 160mm rear)
Brake Levers
Shimano Deore M6100, SERVO WAVE, I-SPEC EV clamps
Drivetrain
1x
Shifters
Shimano SLX M7100, 12-speed, trigger, I-SPEC EV bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed
ISCG Tabs

Chainguide
None
Cranks
FSA Gamma Pro, 2-piece, MegaEXO
Length: 170mm (SM), 175mm (MD-XL)
Chainrings
FSA Gamma Pro, Megatooth profile, 30 tooth
Bottom Bracket
FSA MegaEXO, outboard bearing
Pedals
None
Chain
Shimano SLX M7100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Rims
WTB ST i35 (SM) or i29 (MD-XL) TCS, double wall, 28 hole, tubeless ready
Hubs
Shimano M7110, 110x15mm Boost front, 148x12mm Boost rear with MICRO SPLINE driver
Spokes
14/15g double-butted stainless steel, alloy nipples
Tires
Kenda Hellkat, ATC, 120 TPI, folding, tubeless ready, 27.5" x 2.6" (SM) or 29" x 2.4" (MD-XL)
Saddle
WTB High Tail, CrMo rails
Seatpost
KS Rage-i Integra dropper
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size

Bottle Cage Mounts
One inside front triangle
Colors
Dark Grey
Warranty
2 years frame, 1 year parts/components
Weight

Miscellaneous
External cable routing with internal dropper seatpost routing
Price

More Info

khsbicycles.com
