FOX FLOAT Performance Rear Shock

Related:
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$519.00
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
FOX FLOAT Performance Rear Shock
Riding Type
Cross Country
Trail
Spring Type
Air
External Adjustments
• 2-position lever actuated modes (Open, Firm)
• 3-setting Open mode tuning range
• Rebound damping
• Air spring pressure
Available Sizes
Metric Sizes, trunnion mount:
• 185mm x 50mm
• 185mm x 52.5mm
• 185mm x 55mm

Metric Sizes, standard mount:
• 190mm x 40mm
• 190mm x 42.5mm
• 190mm x 45mm
Weight
0 lb 10.9 oz (310 g)
Miscellaneous
• 2023-2024 version
• Black anodized coating on body and air sleeve
• Large diameter main piston, valving, and Internal Floating Piston (IFP) for increased performance and consistency, plus a wider range of tuning and better damping control
• Lightweight, one-piece EVOL air sleeve improves responsiveness and sensitivity for lower pressures, more linear suspension action, better small bump performance, and better grip at the tires
• Smaller increment (0.1) hybrid volume reducers for ultra-precise tuning
• MCU bottom-out bumper for end-stroke progressivity
• 2-positon switch for zero pre-load on valve stack when in Open mode, and tunable Firm mode
• Remote compatible
• Weight listed for 190mm x 45mm size, including IGUS bushings but not mounting hardware
Price
$349.00
