Yeti SB165 TURQ Frame

spruce 03.jpg?VersionId=IKoXiqZRA.xb1agSPSSm8f6AZYaExVY

raw 03.jpg?VersionId=DZHlhJkfABrqtp1WXjxp2yd89u3Fi

Yeti

Specifications

Product

Yeti SB165 TURQ Frame

Intended Use

Enduro / All-Mountain

Freeride / Bike Park

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	573mm	604mm	625mm	653mm
Head Tube Angle	63.5°	63.5°	63.5°	63.5°
Head Tube Length	95mm	101mm	107mm	118mm
Seat Tube Angle	76.8°	76.9°	76.9°	76.9°
Seat Tube Length	365mm	400mm	440mm	470mm
Bottom Bracket Height	345mm	345mm	345mm	345mm
Chainstay Length	433mm	435mm	437mm	439mm
Wheelbase	1207mm	1242mm	1266mm	1298mm
Standover	730mm	738mm	744mm	750mm
Reach	430mm	460mm	480mm	505mm
Stack	620mm	625mm	630mm	640mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 170mm travel fork with 588mm axle-to-crown length and 44mm offset • Bottom bracket heights are listed as "estimated" by Yeti

Sizes Additional Info

• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• All specifications listed are with 170mm travel fork with 588mm axle-to-crown length and 44mm offset
• Bottom bracket heights are listed as "estimated" by Yeti

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	573mm	604mm	625mm	653mm
Head Tube Angle	63.5°	63.5°	63.5°	63.5°
Head Tube Length	95mm	101mm	107mm	118mm
Seat Tube Angle	76.8°	76.9°	76.9°	76.9°
Seat Tube Length	365mm	400mm	440mm	470mm
Bottom Bracket Height	345mm	345mm	345mm	345mm
Chainstay Length	433mm	435mm	437mm	439mm
Wheelbase	1207mm	1242mm	1266mm	1298mm
Standover	730mm	738mm	744mm	750mm
Reach	430mm	460mm	480mm	505mm
Stack	620mm	625mm	630mm	640mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 170mm travel fork with 588mm axle-to-crown length and 44mm offset • Bottom bracket heights are listed as "estimated" by Yeti

Wheel Size

Mixed Wheel Size

Frame Material

Carbon Fiber

Frame Material Details

TURQ Series carbon fiber front and rear triangles, molded chainstay and seatstay protection, dual-density down tube protection

Rear Travel

165mm

Rear Shock

FOX DHX2 Factory, 2-position platform lever, 230mm length x 65mm stroke

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

73mm English/BSA threaded

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

27.5" x 2.6"

ISCG Tabs

ISCG05

Bottle Cage Mounts

One inside front triangle

Colors

Raw Gloss, Spruce Gloss

Warranty

Lifetime frame and Switch Infinity Link, 1 year paint and finish

Weight

8 lb 10.7 oz (3,933 g)

Miscellaneous

• 2024-2026 version
• Switch Infinity rear suspension design
• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Internally tunneled cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Compatible with dual-crown forks
• Designed for 170mm forks; compatible with up to 190mm fork travel (607mm max axle-to-crown length)
• 180mm post-mount rear brake tabs; 203mm max rear rotor

Price

$4,800.00

More Info

Yeti Updates the SB165 (press release)

REVIEW - The Updated 2024 Yeti SB165

Yeti website
