Specifications

Product

Knolly Delirium Frame

Intended Use

Downhill

Freeride / Bike Park

Rider

Unisex

Sizes and Geometry

S2/SM (Neutral, Slack)

S3/MD (Neutral, Slack)

S4/LG (Neutral, Slack)

S5/XL (Neutral, Slack)

View Full Geometry

Size	S2/SM (Neutral, Slack)	S3/MD (Neutral, Slack)	S4/LG (Neutral, Slack)	S5/XL (Neutral, Slack)
Top Tube Length	589mm	616mm	643mm	670mm
Head Tube Angle	63.25°, 62.50°	63.25°, 62.50°	63.25°, 62.50°	63.25°, 62.50°
Head Tube Length	105mm	115mm	125mm	135mm
Seat Tube Angle	77.75°, 76.00°	77.75°, 76.00°	77.75°, 76.00°	77.75°, 76.00°
Seat Tube Length	350mm	390mm	440mm	490mm
Bottom Bracket Height	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)
Chainstay Length	439mm	443mm	447mm	451mm
Wheelbase	1243mm	1285mm	1318mm	1352mm
Standover	690mm	720mm	745mm	760mm
Reach	457mm	480mm	506mm	531mm
Stack	612mm	621mm	630mm	639mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • Geometry adjustable via two-position flip chip at lower shock mount • All specifications listed are with 200mm travel fork with 600mm axle-to-crown length

Sizes Additional Info

• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Geometry adjustable via two-position flip chip at lower shock mount
• All specifications listed are with 200mm travel fork with 600mm axle-to-crown length

View Full Geometry

Size	S2/SM (Neutral, Slack)	S3/MD (Neutral, Slack)	S4/LG (Neutral, Slack)	S5/XL (Neutral, Slack)
Top Tube Length	589mm	616mm	643mm	670mm
Head Tube Angle	63.25°, 62.50°	63.25°, 62.50°	63.25°, 62.50°	63.25°, 62.50°
Head Tube Length	105mm	115mm	125mm	135mm
Seat Tube Angle	77.75°, 76.00°	77.75°, 76.00°	77.75°, 76.00°	77.75°, 76.00°
Seat Tube Length	350mm	390mm	440mm	490mm
Bottom Bracket Height	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)	357mm (4.5mm rise), 348mm (4.5mm drop)
Chainstay Length	439mm	443mm	447mm	451mm
Wheelbase	1243mm	1285mm	1318mm	1352mm
Standover	690mm	720mm	745mm	760mm
Reach	457mm	480mm	506mm	531mm
Stack	612mm	621mm	630mm	639mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • Geometry adjustable via two-position flip chip at lower shock mount • All specifications listed are with 200mm travel fork with 600mm axle-to-crown length

Wheel Size

Mixed Wheel Size

Frame Material

Aluminum

Frame Material Details

6066 alloy; molded chainstay and lower down tube protection

Rear Travel

190mm

Rear Shock

205mm length x 65mm stroke
Options: FOX DHX2 Factory, RockShox Vivid Ultimate

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Bottom Bracket

73mm English/BSA threaded

Rear Dropout / Hub Dimensions

12mm x 157mm (SuperBoost)

Front Derailleur Size

Not compatible (1x-specific)

Seatpost Diameter

31.6mm

Max Tire Size

27.5" x 2.6"

ISCG Tabs

ISCG05, removable

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube

Colors

2024: Rising Sun, Rough AF Ano
2025: Raw, Lucky Green Ano, Tough AF Ano

Warranty

Lifetime frame; 1 year pivot bearings, bushings, and fasteners

Weight

Miscellaneous

• 2024-2025 version
• Generation 6 Fourby4 rear suspension design
• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• Geometry adjustable via two-position flip chip at lower shock mount
• Internal cable routing
• SRAM UDH (Universal Derailleur Hanger) compatible; includes Knolly specific CNC aluminum hanger
• Designed for 200mm travel forks; compatible with 190-203mm travel forks
• 180mm post-style rear brake mounts
• Includes seatpost clamp: Knolly, single bolt, 35mm

Price

$3,499.00
