Specifications

Product

Pivot Shuttle AMP'd Pro X0 Eagle Transmission E-Bike

Model Year

2026

Intended Use

Enduro / All-Mountain

Rider

Unisex

Sizes and Geometry

XS (High, Low)

SM (High, Low)

MD (High, Low)

LG (High, Low)

XL (High, Low)

View Full Geometry

Size	XS (High, Low)	SM (High, Low)	MD (High, Low)	LG (High, Low)	XL (High, Low)
Top Tube Length	574.6mm, 575.7mm	604.4mm, 605.5mm	631.8mm, 632.9mm	649.1mm, 650.3mm	671.5mm, 672.7mm
Head Tube Angle	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.4°
Head Tube Length	95mm	110mm	120mm	130mm	140mm
Seat Tube Angle	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°
Seat Tube Length	343.0mm	378.0mm	398.7mm	431.8mm	470.0mm
Bottom Bracket Height	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)
Chainstay Length	443mm	443mm	443mm	443mm	443mm
Wheelbase	1187.8mm, 1189.0mm	1217.6mm, 1218.6mm	1246.9mm, 1247.9mm	1266.2mm, 1267.2mm	1290.5mm, 1291.5mm
Standover	645mm, 640mm	663mm, 658mm	671mm, 666mm	671mm, 666mm	682mm, 677mm
Reach	420mm, 416mm	435mm, 431mm	460mm, 456mm	475mm, 471mm	495mm, 491mm
Stack	613.4mm, 616.3mm	633.0mm, 636.0mm	642.2mm, 645.3mm	651.4mm, 654.5mm	660.5mm, 663.8mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 160mm travel fork with 44mm offset

Sizes Additional Info

• Mixed ("Mullet") wheels: 29" front, 27.5" rear
• All specifications listed are with 160mm travel fork with 44mm offset

View Full Geometry

Size	XS (High, Low)	SM (High, Low)	MD (High, Low)	LG (High, Low)	XL (High, Low)
Top Tube Length	574.6mm, 575.7mm	604.4mm, 605.5mm	631.8mm, 632.9mm	649.1mm, 650.3mm	671.5mm, 672.7mm
Head Tube Angle	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.3°	63.7°, 63.4°
Head Tube Length	95mm	110mm	120mm	130mm	140mm
Seat Tube Angle	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°	76.5°, 76.1°
Seat Tube Length	343.0mm	378.0mm	398.7mm	431.8mm	470.0mm
Bottom Bracket Height	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)	340mm (18mm drop), 335mm (23mm drop)
Chainstay Length	443mm	443mm	443mm	443mm	443mm
Wheelbase	1187.8mm, 1189.0mm	1217.6mm, 1218.6mm	1246.9mm, 1247.9mm	1266.2mm, 1267.2mm	1290.5mm, 1291.5mm
Standover	645mm, 640mm	663mm, 658mm	671mm, 666mm	671mm, 666mm	682mm, 677mm
Reach	420mm, 416mm	435mm, 431mm	460mm, 456mm	475mm, 471mm	495mm, 491mm
Stack	613.4mm, 616.3mm	633.0mm, 636.0mm	642.2mm, 645.3mm	651.4mm, 654.5mm	660.5mm, 663.8mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 160mm travel fork with 44mm offset

Wheel Size

Mixed Wheel Size

E-Bike Class

Class 1: Pedal Assist (Pedelecs)

Motor

Avinox M2S; 130 Nm max continuous torque, 1300 W peak power; 150 Nm max torque in Boost mode for 60 seconds

Battery

Avinox, integrated

Battery Capacity

800 Wh

Display/Remote

Avinox DP100 OLED Control Display, top tube integrated, left and right Avinox handlebar remotes

Modes

Auto, Eco, Trail, Turbo, Boost, Intelligent Walk Assist with Auto Hold and Hill Start Assist functions

Max Speed with Assist

USA/Canada/New Zealand: 20 mph (32.2 km/h)

Other: 15.5 mph (25 km/h)

Frame Material

Carbon Fiber

Frame Material Details

Carbon front and rear triangles, molded swingarm (chainstay, seatstay, and upright) and lower down tube protection

Rear Travel

150mm

Rear Shock

RockShox Super Deluxe Ultimate, trunnion mount, 185mm length x 55mm stroke

Fork

RockShox ZEB Ultimate, 38mm stanchions, 44mm offset

Fork Travel

160mm

Head Tube Diameter

Tapered

Headset

Pivot Precision, sealed cartridge bearings, ZS49 upper, ZS56 lower

Handlebar

Phoenix Team Carbon
XS: 760mm width, 20mm rise; SM: 780mm width, 20mm rise; MD-XL: 780mm width, 35mm rise

Stem

Phoenix Team Enduro V2
Length: 35mm (XS), 40mm (SM-LG), 50mm (XL)

Grips

Phoenix Factory, lock-on

Brakes

SRAM Maven Silver, 4-piston
Rotors: SRAM HS2, 6-bolt, 200mm

Brake Levers

SRAM Maven Silver Stealth, tool-free reach adjust and contact point adjust

Drivetrain

Shifters

SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless

Front Derailleur

None

Rear Derailleur

SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless, powered by main battery

Chainguide

Upper keeper

Cranks

Praxis Alloy eCranks, ISIS spindle, 155mm length

Chainrings

34 tooth, with alloy bashring

Pedals

None

Chain

SRAM X0 Eagle Transmission Flattop, 12-speed

Cassette

SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth

Rims

DT Swiss Hybrid HX 1501 Alloy, 30mm width

Hubs

DT Swiss Hybrid wheelset, 20mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) rear with XD driver

Spokes

DT Swiss Hybrid wheelset

Tires

Front: Continental Kyrptotal F, Super Soft compound, Enduro casing, 29" x 2.4"
Rear: Continental Kyrptotal R, Soft compound, Enduro casing, 27.5" x 2.6"

Saddle

Pivot Team E-Bike

Seatpost

OneUp V3 dropper
Drop: 150mm (XS/SM), 180mm (MD), 210mm (LG), 240mm (XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

12mm x 157mm (SuperBoost+)

Max. Tire Size

29" x 2.5" or 27.5" x 2.6"

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube, compatible with Pivot Tool Dock System

Colors

Burgundy Berry Freeze, Black Metallic Stone

Warranty

Lifetime frame; 5 years Pivot/Phoenix components; 1 year paint/finish

Weight

Miscellaneous

• dw-link rear suspension design
• Mixed ("Mullet") wheels: 29" front, 27.5" rear; SM-XL sizes compatible with 29" rear wheels via two-position flip chip in upper linkage
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Avinox SmoothShift technology: drive unit automatically detects gear changes to reduce power for smoother gear shifts, and allows gear changes while coasting; can be activated or deactivated via Control Display
• SRAM AXS derailleur is powered by main battery; if battery is depleted, a partitioned power reserve ensures the derailleur still functions so riders can continue to shift for the remainder of the ride
• USB-C charging port for external devices (phones, GoPro, GPS, etc.)
• Supports a fully-integrated front light powered by the Avinox system and controlled through the display interface, with internal wire routing and dedicated stem-mounted accessory bracket
• Power settings customizable via Avinox Ride Mobile App
• Includes Avinox 508W Fast battery charger
• European price: 11999 EUR

Price

$11,999.00
