2024 Orbea Wild H10 E-Bike

h10 basalt 01
h10 basalt 01
h10 basalt 02
h10 basalt 03.jpg?VersionId=N kmgvFfjeV9nfV
h10 corn 01
h10 corn 02.jpg?VersionId=Bh50F484OSWdlIuTfWS2U1axcI W
h10 corn 03.jpg?VersionId=qpyV6 kYHgT8RIkKipQI7
h10 baobab 01.jpg?VersionId=OkDrCbYAkQ7cx2gCa8Z
h10 baobab 02
h10 baobab 03
display.jpg?VersionId=EjHOKTZHF D.F4nKgz
remote.jpg?VersionId=8.JvY7LGl6ZoXvp5lwQ. 07QharqtTV
h10 basalt 01 h10 basalt 02 h10 basalt 03.jpg?VersionId=7d3LiB4aJxJJu h10 corn 01.jpg?VersionId=z1dpyRhEh4mqBpLAz2cn h10 corn 02.jpg?VersionId=s3E2PwYLoyOzhekaAPM1olUqYt h10 corn 03.jpg?VersionId=K8UNmGWMH6K h10 baobab 01 h10 baobab 02 h10 baobab 03 display.jpg?VersionId=4IDdFlZGuxiytKeEqlvLs remote
Related:
Orbea
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Orbea Wild H10 E-Bike
Model Year
2024
Intended Use
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info
All specifications listed are with 170mm travel fork with 575mm axle-to-crown length and 44mm offset
View Full Geometry
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Bosch Performance Line CX, 85 Nm max torque, 250 W, 36 V
Battery
Bosch PowerTube, integrated
Option: Bosch PowerMore range extender, 250 Wh
Battery Capacity
Standard: 750 Wh
Option: 625 Wh
Display/Remote
Bosch BCR3100 top tube display; Bosch BRC3300 Mini remote, Bluetooth wireless
Option: Bosch Kiox 300 BHU3600 display
Modes
Turbo, Sport/eMTB, Tour, Eco, Walk Assist
Max Speed with Assist
20 mph (32.2 km/h)
Frame Material
Aluminum
Frame Material Details
AL6061 hydroformed alloy; molded down tube, chainstay, and seatstay protection; custom molded motor skid plate
Rear Travel
160mm
Rear Shock
FOX FLOAT X Performance, 2-position compression lever, custom tune, trunnion mount, 205mm x 65mm
Option: FOX FLOAT X2 Factory
Fork
FOX FLOAT 38 Performance, E-Bike Optimized, GRIP damper, 3-position compression lever, 44mm offset
Options: FOX FLOAT 38 Factory, E-Bike Optimized, GRIP2 damper, 160mm travel; FOX FLOAT 38 Factory, GRIP2 damper, 170mm travel
Fork Travel
160mm
Head Tube Diameter
Straight
Headset
Alloy, oxidated bearings, Orbea SIC (Sealed Internal Cables), Spin Block 124° rotation limiter
Handlebar
OC Mountain Control MC20 Alu SL, 800mm width, 20mm rise
Option: OC Mountain Control MC10 Carbon, 800mm width, 20mm or 35mm rise options
Stem
OC Mountain Control MC20, 0° rise
Length: 40mm (SM/MD), 50mm (LG/XL)
Option: OC Mountain Control MC10 Alu SL
Grips
OC, lock-on
Brakes
Shimano Deore M6120, 4-piston
Option: Shimano Deore XT M8120
Brake Levers
Shimano Deore M6100
Option: Shimano Deore XT M8100
Drivetrain
1x
Shifters
Shimano Deore M6100, 12-speed, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+
Chainguide
e*thirteen Plus upper slider
Cranks
e*thirteen Plus Alloy, 165mm length
Chainrings
e*thirteen e*spec, direct mount, 34 tooth
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Rims
OQUO Mountain Control MC32TEAM POWER
Hubs
OQUO Mountain Control MC32TEAM POWER wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
OQUO Mountain Control MC32TEAM POWER wheelset
Tires
Front: Maxxis Assegai, 3C MaxxTerra compound, EXO+ casing, TR, 120 TPI, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 120 TPI, 29" x 2.4" WT
Option: DH casing front/rear
Saddle
fi'zi:k Terra Aidon, 145mm width, manganese rails
Seatpost
OC Mountain Control MC21 dropper, Shimano MT500 I-SPEC EV remote lever
Drop: 125mm (SM), 150mm (MD), 170mm (LG), 200mm (XL); 230mm drop available
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 35mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.6"
Bottle Cage Mounts
One inside front triangle
Colors
Basalt Grey/Dark Teal, Corn Yellow/Metallic Night Black, Baobab Brown/Nori Green
Warranty
Lifetime frame, 3 years paint and finish
Weight

Miscellaneous
• Concentric Boost II rear suspension design
• Secure Battery System (SBS)
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App
• Includes Bosch 4A battery charger (110V)
• Includes OC Computer Mount CM-05 for stem topcap
Price
$6,999.00
More Info

First Ride - Orbea Launches the Fully Redesigned Wild eMTB

Orbea website
