2023 Orbea Rise H20 E-Bike
(discontinued)

Discontinued
20 berry
20 berry.jpg?VersionId=nhy
20 brown
20 grey
remote.jpg?VersionId=ixs7Ll xPK3mrtE.CzkouRnCk6
20 berry 20 brown.jpg?VersionId=lZ8J.kMnlY5whU 20 grey remote.jpg?VersionId=HVzYGVpEurlOO8v7XeM9V7ohPugkY9
Related:
Orbea
Where To Buy
Free shipping on orders over $49 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $49 (continental U.S. only).
International shipping available. Some exclusions apply.
$7,663.95
Orbea Laufey H30
$1,783.95
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$4,899.00
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Orbea Rise H20 E-Bike
Model Year
2023
Intended Use
Enduro / All-Mountain
Trail
Rider
Unisex
Sizes and Geometry
SM (140mm fork, 150mm fork)
MD (140mm fork, 150mm fork)
LG (140mm fork, 150mm fork)
XL (140mm fork, 150mm fork)
View Full Geometry
Sizes Additional Info
All specifications with single values are with 140mm travel fork with 547mm axle-to-crown length and 44mm offset
View Full Geometry
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Shimano STEPS EP600-RS, 60 Nm max torque
Battery
Orbea, integrated
Option: Orbea RS external Range Extender, 252 Wh
Battery Capacity
Standard: 540 Wh
Option: 360 Wh
Display/Remote
Shimano STEPS EN600-L remote, Bluetooth connectivity, wire routed through handlebar
Modes
Boost, Trail, Eco, Walk Assist
Max Speed with Assist
20 mph (32.2 km/h)
Frame Material
Aluminum
Frame Material Details
Hydroformed alloy, triple-butted tubes, molded chainstay and seatstay protection
Rear Travel
140mm
Rear Shock
FOX FLOAT DPS Performance, EVOL, 3-position compression lever, custom tune, trunnion mount, 210mm x 55mm
Option: FLOAT X Performance
Fork
FOX FLOAT 34 Performance, GRIP damper, 3-position compression lever, 44mm offset
Option: FOX FLOAT 36 Performance
Fork Travel
140mm (FOX 34) or 150mm (FOX 36)
Head Tube Diameter
Straight
Headset
Orbea SIC (Sealed Internal Cables); Spin Block rotation limiter
Handlebar
OC Mountain Control MC31, 800mm width, 20mm rise
Stem
OC Mountain Control MC20, 0° rise
Grips

Brakes
Shimano Deore M6120, 4-piston
Brake Levers
Shimano Deore M6120
Drivetrain
1x
Shifters
Shimano SLX M7100, 12-speed, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+
Chainguide
Orbea upper slider
Cranks
Shimano STEPS EM600
Chainrings
e*thirteen e*spec, direct mount, 32 tooth
Pedals
None
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano SLX M7100, 12-speed, 10-51 tooth
Rims
Race Face AR 30c wheelset
Option: OQUO Mountain Control MC32Team
Hubs
Race Face AR 30c wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
Race Face AR 30c wheelset
Tires
Front: Maxxis Dissector, 3C MaxxTerra compound, EXO casing, TR, 60 TPI, 29" x 2.4"
Rear: Maxxis Rekon, 3C MaxxTerra compound, EXO+ compound, 120 TPI, 29" x 2.4"
Front options: Maxxis Rekon, 29" x 2.6"; Maxxis Minion DHF, 29" x 2.5"; Maxxis Assegai, DH casing, 29" x 2.5"
Rear option: Maxxis Minion DHR II, DH casing option, 29" x 2.4"
Saddle
fi'zi:k Taiga, S-Alloy rails, 142mm width
Option: fi'zi:k Taiga, Kium rails
Seatpost
OC Mountain Control MC20 dropper, Shimano MT500 I-SPEC EV remote lever
Drop: 125mm (SM), 150mm (MD), 175mm (LG), 200mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
One inside front triangle
Colors
Baobab Brown/Cosmic Brown, Metallic Mulberry/Black, Iceberg Grey/Moondust Blue
Warranty
Lifetime frame, 2 years paint and finish
Weight

Miscellaneous
• Concentric Boost II rear suspension design
• Rider Synergy (RS) Concept
• Secure Battery System (SBS)
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• Power settings customizable via Shimano STEPS E-Tube Project Mobile App
• Compatible with Garmin IQ ecosystem to display support mode, assist level, cadence, range, and speed data
• Includes Orbea Gen2 Smart 2-4A battery charger (42V)
Price
$5,999.00
