2025 Mondraker Neat R E-Bike

r 01
r 01
r 02
r 03
r 01 r 02 r 03.jpg?VersionId=0IvZ3IdjTay14BAubtrqTDM xnc3DE
Related:
Mondraker
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
$5,499.00
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.
$3,599.00
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Mondraker Neat R E-Bike
Model Year
2025
Intended Use
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info
All specifications listed are with 160mm travel fork with 44mm offset
View Full Geometry
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
TQ HPR50, 300 W max power, 50 Nm max torque
Battery
TQ HRP50, integrated, removable
Optional: TQ 160 Wh external range extender battery
Battery Capacity
360 Wh
Display/Remote
TQ HPR V01 2" top tube display
Modes
Three dynamic assist modes (Eco, Mid and High) plus walk assist; each mode can be individually adjusted via the app for max power, assistance, and pedal response
Max Speed with Assist
USA/Canada/New Zealand: 20 mph (32.2 km/h)
Other: 15.5 mph (25 km/h)
Frame Material
Carbon Fiber
Frame Material Details
Stealth Air carbon front and rear triangles, one-piece Monoblock upper link, exclusive plastic motor covers, molded chainstay and seatstay protection
Rear Travel
150mm
Rear Shock
RockShox Super Deluxe Select, 2-position compression lever (Open/Firm), rebound adjust, trunnion mount, 185mm length x 55mm stroke
Fork
RockShox Lyrik Select, e-bike approved, Charger RC damper, low-speed compression adjust, low-speed rebound adjust, 35mm stanchions, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Straight, 1.5"
Headset
ACROS custom, internal cable routing, IS52/ZS56
Handlebar
ONOFF S6 1.0 Carbon, 800mm width, 25mm rise, 8° backsweep, 5° upsweep, 31.8mm clamp diameter
Stem
ONOFF S6, 6061 forged and CNC alloy, 30mm length, 0° rise, 31.8mm bar clamp
Grips
ONOFF Forest, 135mm length, CNC alloy lock-on
Brakes
SRAM DB8, 4-piston, steel-backed organic pads
Rotors: SRAM CenterLine, 6-bolt, 200mm
Brake Levers
SRAM DB8 Stealth, tooled reach adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless, MMX mounting bracket
Front Derailleur
None
Rear Derailleur
SRAM S1000 Eagle Transmission, 12-speed, AXS electronic wireless
Chainguide
Upper slider
Cranks
e*thirteen Helix Core e*spec Plus Alloy, 160mm length
Chainrings
SRAM Eagle Transmission, steel, X-SYNC 2, narrow/wide profile, 34 tooth, 104mm BCD
Pedals
None
Chain
SRAM GX Eagle Transmission Flattop, 12-speed, with PowerLock
Cassette
SRAM Eagle Transmission XS-1270, 12-speed, 10-52 tooth
Rims
Mavic E-CrossRide Alloy, 30mm inner width, welded, PFP (Pinch Flat Protection) technology, 28 hole, tubeless ready
Hubs
Mavic, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with ID360 freehub and HG driver
Spokes
Mavic, J-bend, double-butted, contactless lacing
Tires
Front: Maxxis Minion DHF, 3C MaxxGrip compound, EXO+ casing, TR, 60 TPI, 29" x 2.5" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, EXO+ casing, TR, 60 TPI, 29" x 2.5" WT
Saddle
fi'zi:k Terra Aidon Slim X5
Seatpost
ONOFF Pija dropper, adjustable travel, 1x remote lever
Drop: 115-140mm (SM), 135-160mm (MD), 155-180mm (LG), 185-210mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
One inside front triangle, plus accessory mounts under top tube
Colors
Obsidian/Yellow/Grey
Warranty
Lifetime main frame with registration; 2 years paint, rear triangle, and links
Weight
41 lb 11.2 oz (18915 g)
Miscellaneous
• E-Bike Optimized Zero Suspension System
• Mondraker Forward Geometry
• HHG (Hidden Housing Guide) internal cable routing through headset
• Integrated dropout speed sensor
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via TQ E-Bike smartphone app
• Includes Mondraker custom design Fidlock smoked transparent 600ml bottle and Fidlock base down version mount
Price
$8,399.00
