Specifications

Product
Mondraker Level R E-Bike
Model Year
2026
Intended Use
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
SM (Standard, Low)
MD (Standard, Low)
M/L (Standard, Low)
LG (Standard, Low)
XL (Standard, Low)
View Full Geometry
Sizes Additional Info
• Geometry adjustable via two-position flip chip in lower shock mount


• All specifications listed are with 180mm travel fork with 44mm offset
View Full Geometry
Wheel Size
29"
E-Bike Class
Class 1: Pedal Assist (Pedelecs)
Motor
Bosch Performance Line CX, Smart System, 100 Nm max torque, 750 W max power, 400% max assist
Battery
Bosch Powertube, integrated, removable, carbon cover
Option: Bosch 250 Wh range extender
Battery Capacity
800 Wh
Display/Remote
Bosch Purion 400 display and Bosch System Controller, Bosch 3-button Bluetooth wireless Mini Remote
Modes
Turbo, eMTB, Tour+, Eco, Walk Assist
Max Speed with Assist
USA/Canada/New Zealand: 20 mph (32.2 km/h)
Other: 15.5 mph (25 km/h)
Frame Material
Aluminum
Frame Material Details
6061 Alloy Stealth Evo, one-piece Monoblock upper link, exclusive plastic motor covers, molded chainstay protection
Rear Travel
170mm
Rear Shock
RockShox Vivid Coil Base, external bottom-out adjust, low-speed rebound adjust, trunnion mount, 205mm length x 65mm stroke
Spring rates: 350lbs (SM), 400lbs (MD), 450lbs (M/L), 500lbs (LG/XL)
Fork
RockShox ZEB Select, Charger RC damper, low-speed compression adjust, low-speed rebound adjust, 38mm stanchions, 44mm offset
Fork Travel
180mm
Head Tube Diameter
Straight, 1.5"
Headset
ONOFF, ACB sealed bearings, ZS56
Handlebar
ONOFF S3 1.0, 6061 alloy, 800mm width, 8° backsweep, 5° upsweep, 31.8mm clamp diameter
Rise: 25mm (SM-M/L), 38mm (LG/XL)
Stem
ONOFF S3, 6061 forged alloy, 0° rise, 30mm length, 31.8mm bar clamp
Grips
ONOFF Desert Pro, 135mm length, single CNC alloy lock-on
Diameter: standard (SM-M/L), thick (LG/XL)
Brakes
SRAM Maven Bronze, 4-piston, steel-backed sintered metal pads
Rotors: SRAM HS2, 6-bolt, 220mm front, 200mm rear
Brake Levers
SRAM Maven Bronze Stealth, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM Eagle 90 Transmission, 12-speed, Single Click
Front Derailleur
None
Rear Derailleur
SRAM Eagle 90 Transmission, 12-speed
Chainguide
Upper slider
Cranks
Race Face Aeffect E-Bike, 160mm length
Chainrings
SRAM Eagle Transmission, X-SYNC 2, steel, narrow/wide profile, 34 tooth, 104mm BCD
Pedals
None
Chain
SRAM Eagle 70 Transmission Flattop, 12-speed
Cassette
SRAM Eagle Transmission XS-1270, 12-speed, 10-52 tooth
Rims
e*thirteen Grappler Core, hookless 6066 welded aluminum, 30mm inner width, 28 hole, tubeless ready
Hubs
e*thirteen, triple-sealed, fully machined aluminum, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with 6° engagement freehub and HG driver
Spokes
e*thirteen custom, J-bend, triple-butted steel, alloy nipples with washers
Tires
Front: Maxxis Assegai, 3C MaxxGrip compound, DoubleDown (DD) casing, TR, 2x 120 TPI, 29" x 2.6" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, TR, 2x 120 TPI, 27.5" x 2.6" WT
Saddle
fi'zi:k Terra Aidon X5, 145mm width
Seatpost
ONOFF Pija dropper, adjustable travel, 1x remote lever
Drop: 115-140mm (SM), 135-160mm (MD), 155-180mm (M/L), 185-210mm (LG/XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
One inside front triangle, plus accessory mounts under top tube
Colors
Chili Red/Superblack
Warranty
Lifetime frame with registration, 3 years rear triangle and paint
Weight
58 lb 14.4 oz (26717 g)
Miscellaneous
• E-Bike Optimized Zero Suspension System
• Mondraker Forward Geometry
• Geometry adjustable via two-position flip chip in lower shock mount
• HHG (Hidden Housing Guide) internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App
Price
$6,999.00
