Specifications

Product

Mondraker Level XR E-Bike

Model Year

2026

Intended Use

Enduro / All-Mountain

Freeride / Bike Park

Rider

Unisex

Sizes and Geometry

SM (Standard, Low)

MD (Standard, Low)

M/L (Standard, Low)

LG (Standard, Low)

XL (Standard, Low)

View Full Geometry

Size	SM (Standard, Low)	MD (Standard, Low)	M/L (Standard, Low)	LG (Standard, Low)	XL (Standard, Low)
Top Tube Length	567mm, 577mm	598mm, 599mm	620mm, 621mm	642mm, 643mm	664mm, 665mm
Head Tube Angle	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°
Head Tube Length	110mm	120mm	130mm	140mm	150mm
Seat Tube Angle	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°
Seat Tube Length	380mm	410mm	435mm	460mm	490mm
Bottom Bracket Height	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)
Chainstay Length	445mm, 446mm	445mm, 446mm	445mm, 446mm	445mm, 446mm	445mm, 446mm
Wheelbase	1236mm, 1237mm	1260mm, 1261mm	1284mm, 1285mm	1319mm, 1320mm	1343mm, 1344mm
Reach	440mm, 436mm	460mm, 456mm	480mm, 476mm	500mm, 496mm	520mm, 516mm
Stack	640mm, 643mm	649mm, 652mm	658mm, 661mm	667mm, 670mm	676mm, 679mm
Additional Info	• Geometry adjustable via two-position flip chip in lower shock mount • All specifications listed are with 180mm travel fork with 44mm offset

Sizes Additional Info

• Geometry adjustable via two-position flip chip in lower shock mount

• All specifications listed are with 180mm travel fork with 44mm offset

View Full Geometry

Size	SM (Standard, Low)	MD (Standard, Low)	M/L (Standard, Low)	LG (Standard, Low)	XL (Standard, Low)
Top Tube Length	567mm, 577mm	598mm, 599mm	620mm, 621mm	642mm, 643mm	664mm, 665mm
Head Tube Angle	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°	64.0°, 63.65°
Head Tube Length	110mm	120mm	130mm	140mm	150mm
Seat Tube Angle	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°	78.0°, 77.65°
Seat Tube Length	380mm	410mm	435mm	460mm	490mm
Bottom Bracket Height	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)	353mm (2mm drop), 348mm (7mm drop)
Chainstay Length	445mm, 446mm	445mm, 446mm	445mm, 446mm	445mm, 446mm	445mm, 446mm
Wheelbase	1236mm, 1237mm	1260mm, 1261mm	1284mm, 1285mm	1319mm, 1320mm	1343mm, 1344mm
Reach	440mm, 436mm	460mm, 456mm	480mm, 476mm	500mm, 496mm	520mm, 516mm
Stack	640mm, 643mm	649mm, 652mm	658mm, 661mm	667mm, 670mm	676mm, 679mm
Additional Info	• Geometry adjustable via two-position flip chip in lower shock mount • All specifications listed are with 180mm travel fork with 44mm offset

Wheel Size

29"

E-Bike Class

Class 1: Pedal Assist (Pedelecs)

Motor

Bosch Performance Line CX, Smart System, 100 Nm max torque, 750 W max power, 400% max assist

Battery

Bosch Powertube, integrated, removable, carbon cover
Option: Bosch 250 Wh range extender

Battery Capacity

800 Wh

Display/Remote

Bosch Kiox 400 display, Bosch 3-button Bluetooth wireless Mini Remote

Modes

Turbo, eMTB, Tour+, Eco, Walk Assist

Max Speed with Assist

USA/Canada/New Zealand: 20 mph (32.2 km/h)

Other: 15.5 mph (25 km/h)

Frame Material

Aluminum

Frame Material Details

6061 Alloy Stealth Evo, one-piece Monoblock upper link, exclusive plastic motor covers, molded chainstay protection

Rear Travel

170mm

Rear Shock

Öhlins TTX22M.2, high speed compression lever with climb mode, low-speed compression adjust, rebound adjust, trunnion mount, 205mm length x 65mm stroke
Spring rates: 343lbs (SM), 411lbs (MD), 457lbs (M/L), 502lbs (LG/XL)

Fork

Öhlins RXF 38 M.2, TTX18 Twin Tube cartridge damper, high-speed compression lever with climb mode, low-speed compression adjust, rebound adjust, ramp chamber, 44mm offset

Fork Travel

180mm

Head Tube Diameter

Straight, 1.5"

Headset

ONOFF, ACB sealed bearings, ZS56

Handlebar

ONOFF S9 1.0 Carbon, 800mm width, 8° backsweep, 5° upsweep, 31.8mm clamp diameter
Rise: 25mm (SM-M/L), 38mm (LG/XL)

Stem

ONOFF S9, CNC alloy, 0° rise, 30mm length, 31.8mm bar clamp

Grips

ONOFF Desert Pro, 135mm length, single CNC alloy lock-on
Diameter: standard (SM-M/L), thick (LG/XL)

Brakes

SRAM Maven Silver, 4-piston, steel-backed sintered metal pads
Rotors: SRAM HS2, 6-bolt, 220mm front, 200mm rear

Brake Levers

SRAM Maven Silver Stealth, tool-free reach adjust and contact point adjust

Drivetrain

Shifters

SRAM Eagle Pod Controller, 12-speed, AXS electronic wireless, MMX mounting bracket

Front Derailleur

None

Rear Derailleur

SRAM GX Eagle Transmission, 12-speed, AXS electronic wireless

Chainguide

Upper slider

Cranks

Race Face Aeffect E-Bike, 160mm length

Chainrings

SRAM Eagle Transmission, X-SYNC 2, steel, narrow/wide profile, 34 tooth, 104mm BCD

Pedals

None

Chain

SRAM GX Eagle Transmission Flattop, 12-speed

Cassette

SRAM GX Eagle Transmission XS-1275, 12-speed, 10-52 tooth

Rims

e*thirteen Grappler Race, hookless 6069 welded aluminum, 30mm inner width, 28 hole, tubeless ready

Hubs

e*thirteen, triple-sealed, fully machined aluminum, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with 6° engagement freehub and XD driver

Spokes

e*thirteen custom, J-bend, triple-butted steel, alloy nipples with washers

Tires

Front: Maxxis Assegai, 3C MaxxGrip compound, DoubleDown (DD) casing, TR, 2x 120 TPI, 29" x 2.6" WT
Rear: Maxxis Minion DHR II, 3C MaxxTerra compound, DoubleDown (DD) casing, TR, 2x 120 TPI, 27.5" x 2.6" WT

Saddle

fi'zi:k Terra Aidon X5, 145mm width

Seatpost

ONOFF Pija dropper, adjustable travel, 1x remote lever
Drop: 115-140mm (SM), 135-160mm (MD), 155-180mm (M/L), 185-210mm (LG/XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube

Colors

Dense Yellow/Superblack

Warranty

Lifetime frame with registration, 3 years rear triangle and paint

Weight

57 lb 1.6 oz (25900 g)

Miscellaneous

• E-Bike Optimized Zero Suspension System
• Mondraker Forward Geometry
• Geometry adjustable via two-position flip chip in lower shock mount
• HHG (Hidden Housing Guide) internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Power settings customizable via Bosch eBike Flow Mobile App

Price

$9,999.00

More Info

Mondraker website
