Specifications

Product
Trek Procaliber 6 Bike
Model Year
2024
Intended Use
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
SM
MD
ML
LG
XL
View Full Geometry
Sizes Additional Info
All specifications listed are with 120mm travel fork with 43mm offset
View Full Geometry
Wheel Size
29"
Frame Material
Aluminum
Frame Material Details
Alpha Platinum cold-extruded hydroformed butted alloy, molded chainstay protection
Rear Travel
Hardtail
Rear Shock
None
Fork
RockShox Judy Silver, Solo Air spring, TurnKey damper with lockout, 42mm offset, Maxle Stealth thru-axle
Fork Travel
120mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Semi-integrated, loose ball bearings
Handlebar
Bontrager, alloy, 31.8mm clamp diameter
SM/MD: 720mm width, 5mm rise; ML-XL: 750mm width, 15mm rise
Stem
7° rise, 31.8mm bar clamp
SM: Bontrager Comp, 50mm length; MD/ML: Bontrager Elite, 60mm length; LG: Bontrager Elite, 70mm length; XL: Bontrager Elite, 80mm length
Grips
Bontrager XR Trail Comp, nylon lock-on
Brakes
Shimano MT200, 2-piston, Shimano RT10 CENTER LOCK rotors (180mm front, 160mm rear)
Brake Levers
Shimano MT200
Drivetrain
1x
Shifters
Shimano Deore M6100, 12-speed
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, long cage
ISCG Tabs
None
Chainguide
None
Cranks
Shimano MT512
Length: 170mm (SM/MD), 175mm (ML-XXL)
Chainrings
Shimano MT512, 30 tooth
Bottom Bracket
Shimano MT501, 73mm English/BSA threaded
Pedals
VP-536 nylon platform
Chain
Shimano Deore M6100, 12-speed
Cassette
Shimano Deore M6100, 12-speed, 10-51 tooth
Rims
Bontrager Kovee, double-wall alloy, 28 hole, 23mm inner width, tubeless ready
Hubs
Shimano TC500 alloy, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes

Tires
Bontrager Sainte-Anne Pro XR, dual compound, aramid bead, tubeless ready, 60 TPI, 29" x 2.2"
Saddle
Bontrager Verse Short, steel rails, 145mm width
Seatpost
Bontrager Line dropper, MaxFlow
Drop: 100mm (SM/MD), 150mm (ML/LG), 170mm (XL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.4"
Bottle Cage Mounts
Two inside front triangle
Colors
Satin Trek Black/Lithium Grey, Viper Red/Crimson
Warranty
Lifetime frame, 2 years Trek/Bontrager parts and paint/decals
Weight
27 lb 12.5 oz (12,600 g)
Miscellaneous
• Internal cable routing
• Hidden rack and kickstand mounts
• SRAM UDH (Universal Derailleur Hanger)
• Includes Bontrager TLR tubeless rim strips, valve stems, and sealant
• Weight given for size MD set up tubeless
Price
$1,699.99
