Specifications

Product
Pivot Mach 6 Pro XT Di2 Bike
Model Year
2025
Intended Use
Enduro / All-Mountain
Rider
Unisex
Sizes and Geometry
XS 27.5" (Low, High)
SM 27.5" (Low, High)
MD 27.5" (Low, High)
LG 27.5" (Low, High)
XS MX (Low, High)
SM MX (Low, High)
MD MX (Low, High)
LG MX (Low, High)
View Full Geometry
Sizes Additional Info
• Available with 27.5" wheels front/rear or mixed ("Mullet") wheels: 29" front, 27.5" rear
• Geometry adjustable via two-position flip chip in upper linkage
• All specifications listed are with 160mm travel fork with 44mm offset
View Full Geometry
Wheel Size
27.5" (650b)
Mixed Wheel Size
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core carbon fiber front and rear triangles, size-specific carbon layups; molded down tube, seatstay, and chainstay protection
Rear Travel
158mm
Rear Shock
FOX FLOAT X2 Factory, Kashima coating, trunnion mount, 205mm length x 65mm stroke
Fork
27.5": FOX FLOAT 38 Factory, GRIP2 damper, Kashima coating, 44mm offset
29": FOX FLOAT 36 Factory, GRIP X2 damper, Kashima coating, 44mm offset
Fork Travel
160mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed cartridge bearings
Handlebar
Phoenix Team Low Rise Carbon
Width: 760mm (XS), 780mm (SM), 800mm (MD-XL)
Stem
Phoenix Team Enduro/Trail, 45mm length
Grips
Phoenix Factory, lock-on
Brakes
Shimano Deore XT M8220, 4-piston
Rotors: Shimano Deore XT, CENTER LOCK, 203mm front, 180mm rear
Brake Levers
Shimano Deore XT
Drivetrain
1x
Shifters
Shimano Deore XT M8250 Di2, 12-speed, electronic wireless, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8250 Di2, 12-speed, electronic wireless, SGS cage
ISCG Tabs
ISCG05
Chainguide
Upper slider
Cranks
Race Face Aeffect R Alloy
Chainrings
Race Face Aeffect R, 32 tooth
Bottom Bracket
92mm press-fit
Pedals
None
Chain
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8200, 12-speed, 10-51 tooth
Rims
DT Swiss XM 1700 Alloy, 30mm width
Option: Reynolds Blacklabel Enduro Wide Trail Carbon, 34mm width
Hubs
DT Swiss 350, 15mm x 110mm (Boost) front, 12mm x 157mm (SuperBoost+) rear with 36-tooth Star Ratchet freehub and MICRO SPLINE driver
Option (with Reynolds Blacklabel Enduro Wide Trail Carbon rims): Industry Nine
Spokes
DT Swiss wheelset
Tires
Maxxis Assegai, 3C MaxxTerra compound, EXO+ casing, TR, 2.5" WT
Saddle
WTB Volt Pro Phoenix, medium width
Seatpost
FOX Transfer Factory dropper, Kashima coating
Drop: 125mm (XS), 150mm (SM), 155-180mm (MD), 210mm LG)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 157mm (SuperBoost+)
Max. Tire Size
27.5" x 2.6"
Bottle Cage Mounts
One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System
Colors
Mint Relic, Stealth
Warranty
10 years frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings
Weight

Miscellaneous
• dw-link rear suspension design
• Available with 27.5" wheels front/rear or mixed ("Mullet") wheels: 29" front, 27.5" rear
• Geometry adjustable via two-position flip chip in upper linkage
• Cable Port System internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights (with FOX FLOAT X2 shock): 6.4lbs (2.9kg) for size XS, 6.7lbs (3.05kg) for size MD
Price
With DT Swiss XM 1700/350 alloy wheelset: $8,699.00
With Reynolds Blacklabel Enduro Wide Trail/Industry Nine carbon wheelset: $10,049.00
