Specifications

Product
Pivot Mach 4 SL Expert XT Di2 Bike
Model Year
2026
Intended Use
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
XS
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info
All specifications listed are with 120mm travel fork with 44mm offset
View Full Geometry
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
High-modulus carbon fiber front and rear triangles; molded chainstay, seatstay, and lower down tube protection
Rear Travel
Setting one: 110mm
Setting two: 120mm
Rear Shock
FOX FLOAT Performance, 190mm length x 45mm stroke
Fork
FOX FLOAT 34 SL Performance, GRIP damper, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Straight, 52mm
Headset
Pivot Precision, sealed integrated cartridge bearings, IS52 upper/lower
Handlebar
Phoenix Team Flat Carbon, 760mm width
Stem
Phoenix Team XC/Trail, 60mm length
Grips
Phoenix Factory, lock-on
Brakes
Shimano Deore XT M8200, 2-piston
Rotors: Shimano RT86, 6-bolt, 180mm front, 160mm rear
Brake Levers
Shimano Deore XT
Drivetrain
1x
Shifters
Shimano Deore XT M8250 Di2, 12-speed, electronic wireless, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8250 Di2, 12-speed, electronic wireless, SGS cage
ISCG Tabs
ISCG05 forward two bolts
Chainguide
None
Cranks
Race Face Aeffect R Alloy
Chainrings
Race Face Aeffect R, 34 tooth
Bottom Bracket
92mm press-fit
Pedals
None
Chain
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8200, 12-speed, 10-51 tooth
Rims
DT Swiss X 1900 Alloy, 25mm width
Hubs
DT Swiss, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
DT Swiss wheelset
Tires
Front: Maxxis Rekon, 3C MaxxTerra compound, EXO casing, TR, 120 TPI, 29" x 2.4"
Rear: Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4"
Saddle
WTB Volt Pro Phoenix, narrow width
Seatpost
JD/Pivot YSP23GLS dropper
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.4"
Bottle Cage Mounts
One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System
Colors
Blue Stellar Fade, White Avalanche
Warranty
10 years frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings
Weight

Miscellaneous
• XC-Tuned dw-link rear suspension design
• Rear travel adjustable via two-position flip chip in linkage/upper shock mount
• Toolshed internal storage in down tube; includes custom made storage bags
• Internal cable routing with Pivot Cable Port System
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights start at 2500 g (5.5 lbs) with FOX FLOAT shock
• Photos may show alternate builds
