2025 Pivot Mach 4 SL Team XX SL Eagle Transmission Bike

team xx green.png?VersionId=e.nw4ADlO1kvEXonD.XmojNEF1d
team xx green.png?VersionId=qiGe
team xx blue
team xx midnight
chip
detail
team xx green.png?VersionId=e.nw4ADlO1kvEXonD.XmojNEF1d team xx blue team xx midnight.png?VersionId=VxR22Pz6NX chip detail.png?VersionId=y4
Related:
Pivot
Where To Buy
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.
$11,999.00
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (contiguous U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Pivot Mach 4 SL Team XX SL Eagle Transmission Bike
Model Year
2025
Intended Use
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
XS
SM
MD
LG
XL
View Full Geometry
Sizes Additional Info
• All specifications listed are with 120mm travel fork with 44mm offset


• Effective seat tube angles are calculated at an average saddle height for each size frame
View Full Geometry
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
Hollow Core carbon fiber front and rear triangles, size-specific carbon layups; injection-molded rubberized chainstay, seatstay, and lower down tube protection
Rear Travel
Setting one: 106mm
Setting two: 115mm
Rear Shock
FOX FLOAT Factory, Kashima coating, 190mm length x 45mm stroke
Option (outside USA): TwistLoc remote lockout
Fork
FOX FLOAT 34 Step-Cast (SC) Factory, GRIP SL damper, Kashima coating, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Pivot Precision, sealed integrated cartridge bearings
Handlebar
Phoenix Team Flat Carbon, 760mm width
Stem
Phoenix Team XC/Trail, 60mm length
Grips
Phoenix Factory, lock-on
Brakes
SRAM Level Ultimate, 2-piston
Rotors: SRAM CenterLine, CENTER LOCK, 160mm
Brake Levers
SRAM Level Ultimate Stealth, carbon blade, tool-free reach adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Ultimate Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM XX SL Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
ISCG05 upper two tabs
Chainguide
None
Cranks
SRAM XX SL Eagle Transmission Carbon DUB
Chainrings
SRAM XX SL Eagle Transmission, 34 tooth
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM XX SL Eagle Transmission Flattop, 12-speed
Cassette
SRAM XX SL Eagle Transmission XS-1299, 12-speed, 10-52 tooth
Rims
Reynolds Blacklabel XC Carbon, 309 30mm-width front, 289 28mm-width rear
Hubs
Industry Nine Hydra, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver
Spokes

Tires
Front: Maxxis Rekon, 3C compound, EXO casing, TR, 120 TPI, 29" x 2.4"
Rear: Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4"
Saddle
WTB Volt World Cup Phoenix, carbon rails, medium width
Seatpost
RockShox Reverb AXS dropper, electronic wireless
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt, 36.4mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
29" x 2.4"
Bottle Cage Mounts
One inside front triangle, one under down tube, plus accessory mounts under top tube; compatible with Pivot Dock Tool System
Colors
Ice Blue, Seafoam Green, Midnight Sky
Warranty
10 years frame, 5 years Pivot/Phoenix components, 1 year paint/finish/bearings
Weight

Miscellaneous
• XC-Tuned dw-link rear suspension design
• Rear travel adjustable via two-position flip chip in linkage/upper shock mount
• Internal cable routing with Pivot Cable Port System
• SRAM UDH (Universal Derailleur Hanger)
• Frame weights start at 1660 g (3.65 lbs)
Price
$11,599.00
