Specifications

Product
Orbea Oiz M-Pro Bike
Model Year
2024
Riding Type
Cross Country
Trail
Rider
Unisex
Sizes and Geometry
SM
MD
LG
XL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
OMX carbon front and rear triangles, FiberLink upper linkage, molded chainstay protection
Rear Travel
120mm
Rear Shock
FOX FLOAT SL Factory, EVOL, OC Squidlock MP20 3-position remote lockout, Kashima coating, custom tune, 190mm lengh x 45mm stroke
Fork
FOX FLOAT 34 Step-Cast (SC) Factory, FIT4 damper, OC Squidlock MP20 3-position remote lockout, Kashima coating, 44mm offset
Fork Travel
120mm
Head Tube Diameter
Straight
Headset
Orbea SIC (Sealed Internal Cables); Spin Block rotation limiter, oxidated bearings
Handlebar
OC MP10 Mountain Performance Carbon, 760mm width, 9° sweep
Option: OC MC10 CB SL, 800mm width, 35mm rise
Stem
OC MP10 Mountain Performance Alu SL, 10° drop
Length: 60mm (SM), 75mm (MD/LG), 90mm (XL)
Option: OC MC10, 0° rise, 40mm or 50mm length options
Grips
Silicone foam, slip-on
Brakes
Shimano Deore XT M8100, 2-piston
Option: Shimano XTR M9100, 2-piston
Brake Levers
Shimano Deore XT M8100
Option: Shimano XTR M9100
Drivetrain
1x
Shifters
Shimano Deore XT M8100, 12-speed, I-SPEC EV mounting bracket
Front Derailleur
None
Rear Derailleur
Shimano Deore XT M8100, 12-speed, SGS cage, SHADOW RD+
ISCG Tabs
None
Chainguide
None
Cranks
Shimano Deore XT M8120
Length: 170mm (SM), 175mm (MD-XL)
Option: 4iiii Powermeter Pod 300
Chainrings
Shimano Deore XT M8120, 34 tooth
Bottom Bracket
English/BSA threaded
Pedals
None
Chain
Shimano Deore XT M8100, 12-speed
Cassette
Shimano Deore XT M8100, 12-speed, 10-51 tooth
Rims
OQUO Mountain Performance MP30Team Carbon, hookless, 30mm inner width
Option: OQUO Mountain Performance MP30LTD Carbon
Hubs
OQUO Mountain Performance MP30Team wheelset, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver
Spokes
OQUO Mountain Performance MP30Team wheelset
Tires
Maxxis Rekon Race, EXO casing, TR, 120 TPI, 29" x 2.4"
Option: Schwalbe Wicked Will, EVO line, Addix SpeedGrip compound, TLE, 29" x 2.4"
Saddle
Selle Italia SLR Boost Fill, titanium rails
Options: Selle Italia SLR Boost Fill, carbon rails; Selle Italia SLR Boost SuperFlow
Seatpost
FOX Transfer SL Factory dropper, Kashima coating, 100/125/150mm drop options; remote lever integrated with OC Squidlock MP20 suspension lever
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size

Bottle Cage Mounts
Two inside front triangle
Colors
Digital Lavender/Carbon Raw, Tanzanite Carbon View/Carbon Raw, Wine Red Carbon View/Titan; customizable via Orbea MyO program
Warranty
Lifetime frame, 3 years paint and finish
Weight

Miscellaneous
• Advanced Dynamics UFO flexstay single pivot rear suspension design
• SIC (Sealed Internal Cables) routing; cables/hoses route through headset
• Frame weight: 1740g
Price
$6,599.00
