Specifications

Product
Norco Optic C1 Bike
Model Year
2025
Intended Use
Trail
Rider
Unisex
Sizes and Geometry
1
2
3
4
5
View Full Geometry
Sizes Additional Info
All specifications listed are with 140mm travel fork with 44mm offset, for a trail value of 128mm (all sizes)
View Full Geometry
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
Carbon front and rear triangles; co-molded shuttle guard, lower down tube, seatstay, and chainstay protection
Rear Travel
125mm
Rear Shock
FOX FLOAT X Factory, Kashima coating, trunnion mount, 185mm length x 50mm stroke
Fork
FOX FLOAT 34 Factory, GRIP X damper, high/low-speed compression adjust, low-speed rebound adjust, Kashima coating, 44mm offset, includes FOX mudguard/fender
Fork Travel
140mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
FSA No.57, sealed bearings, ZS44/28.6 upper, ZS56/40 lower
Handlebar
OneUp Carbon, 800mm width, 20mm rise, 35mm clamp diameter
Stem
OneUp, 42mm length, 35mm bar clamp
Grips
Ergon GE1, Slim (S1/S2) or Standard (S3-S5) diameter
Brakes
SRAM Code Silver, 4-piston, sintered pads, SRAM CenterLine 180mm 6-bolt rotors
Brake Levers
SRAM Code Silver Stealth, tool-free reach adjust and contact point adjust
Drivetrain
1x
Shifters
SRAM Eagle Pod Ultimate Controller, 12-speed, AXS electronic wireless
Front Derailleur
None
Rear Derailleur
SRAM X0 Eagle Transmission, 12-speed, AXS electronic wireless
ISCG Tabs
ISCG05 lower two tabs
Chainguide
Norco integrated upper idler guide and lower guide/bashguard
Cranks
SRAM X0 Eagle Transmission Alloy DUB
Length: 165mm (S1/S2), 170mm (S3-S5)
Chainrings
SRAM X0 Eagle Transmission, 30 tooth
Bottom Bracket
SRAM DUB MTB Wide, 73mm English/BSA threaded
Pedals
None
Chain
SRAM X0 Eagle Transmission Flattop, 12-speed
Cassette
SRAM X0 Eagle Transmission XS-1295, 12-speed, 10-52 tooth
Rims
We Are One Composites Faction Carbon, 27mm inner width, 32 hole
Hubs
Industry Nine 1/1, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with XD driver
Spokes
Stainless steel
Tires
Front: Maxxis Minion DHF, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.5”
Rear: Maxxis Dissector, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.4”
Saddle
Ergon SM-1 Enduro
Seatpost
OneUp V3 adjustable dropper
Max drop: 150mm (S1), 180mm (S2), 210mm (S3/S4), 240mm (S5)
Seatpost Diameter
34.9mm
Seatpost Clamp
Norco alloy, single bolt, 38.5mm
Rear Dropout / Hub Dimensions
12mm x 148mm (Boost)
Max. Tire Size
2.6"
Bottle Cage Mounts
One inside front triangle plus accessory mounts under top tube
Colors
Raw Space Blue
Warranty
Lifetime frame; 2 years suspension hardware; 1 year Norco components, finish, and graphics
Weight
32 lb 6.5 oz (14700 g)
Miscellaneous
• VPS-HP (Virtual Pivot Suspension - High Pivot) rear suspension design
• Norco Ride Aligned Design System
• Includes app-based Ride Aligned Setup Guide with rider-specific suspension, cockpit, and tire pressure suggestions
• Internal cable routing with internal guide tubes
• SRAM UDH (Universal Derailleur Hanger)
• Compatible with 27.5" rear wheel for mixed ("Mullet") setups via Missing Link Kit
• Weight listed for size 3
• Frame weight: 3.1 kg (6.7 lbs)
• Includes OneUp EDC Lite multitool
• Includes We Are One Composites tubeless valves and Stan's NoTubes tire sealant
Price
$9,099.00
