2023 Mondraker Raze Bike

(discontinued)

Discontinued

Mondraker


Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply.	Free shipping on orders over $50 (continental U.S. only). International shipping available. Some exclusions apply. $12,999.00	Buy
Mondraker \| Zendit Rr S E-Bike \| Black \| (Vortex Grey) Xl	Mondraker \| Zendit Rr S E-Bike \| Black \| (Vortex Grey) Xl $12,999.00	Buy
Mondraker \| Zendit Rr E-Bike \| Desert \| (Saturn) Ml	Mondraker \| Zendit Rr E-Bike \| Desert \| (Saturn) Ml $10,699.00	Buy
Mondraker \| Crafty Carbon R E-Bike 2026 \| Golden Silver \| S	Mondraker \| Crafty Carbon R E-Bike 2026 \| Golden Silver \| S $8,499.00	Buy
Mondraker \| Crafty Carbon Rr S E-Bike 2026 \| Dense Yellow \| Ml	Mondraker \| Crafty Carbon Rr S E-Bike 2026 \| Dense Yellow \| Ml $10,999.00	Buy
Free shipping on orders over $50 (contiguous U.S. only). International shipping available. Some exclusions apply.	Free shipping on orders over $50 (contiguous U.S. only). International shipping available. Some exclusions apply. $6,499.00	Buy
Mondraker Summum R Mullet Complete Mountain Bike 2026 - Large	Mondraker Summum R Mullet Complete Mountain Bike 2026 - Large $6,499.00	Buy
Mondraker Arid S Complete Bike 2026 - M/L Size Medium/Large	Mondraker Arid S Complete Bike 2026 - M/L Size Medium/Large $3,199.00	Buy
Mondraker Arid R Complete Bike 2026 - M/L in Silver Size Medium/Large	Mondraker Arid R Complete Bike 2026 - M/L in Silver Size Medium/Large $3,599.00	Buy
Free shipping on orders over $69 (continental U.S. only). International shipping available. Some exclusions apply.	Browse available Bikes
Free U.S. shipping on everything. International shipping available. Some exclusions apply.	Browse available Bikes

Specifications

Product

Mondraker Raze Bike

Model Year

2023

Intended Use

Enduro / All-Mountain

Trail

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	594mm	614mm	638mm	658mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	100mm	100mm	120mm	120mm
Seat Tube Angle	77°	77°	77°	77°
Seat Tube Length	375mm	415mm	445mm	490mm
Bottom Bracket Height	340mm (29mm drop)	340mm (29mm drop)	340mm (29mm drop)	340mm (29mm drop)
Chainstay Length	435mm	435mm	435mm	435mm
Wheelbase	1197mm	1216mm	1246mm	1266mm
Reach	450mm	470mm	490mm	510mm
Stack	623mm	623mm	641mm	641mm
Additional Info	All specifications listed are with 150mm travel fork with 44mm offset

Sizes Additional Info

All specifications listed are with 150mm travel fork with 44mm offset

View Full Geometry

Size	SM	MD	LG	XL
Top Tube Length	594mm	614mm	638mm	658mm
Head Tube Angle	65.5°	65.5°	65.5°	65.5°
Head Tube Length	100mm	100mm	120mm	120mm
Seat Tube Angle	77°	77°	77°	77°
Seat Tube Length	375mm	415mm	445mm	490mm
Bottom Bracket Height	340mm (29mm drop)	340mm (29mm drop)	340mm (29mm drop)	340mm (29mm drop)
Chainstay Length	435mm	435mm	435mm	435mm
Wheelbase	1197mm	1216mm	1246mm	1266mm
Reach	450mm	470mm	490mm	510mm
Stack	623mm	623mm	641mm	641mm
Additional Info	All specifications listed are with 150mm travel fork with 44mm offset

Wheel Size

29"

Frame Material

Aluminum

Frame Material Details

Stealth Evo Alloy, hydroformed tubing, one-piece Monoblock upper link

Rear Travel

130mm

Rear Shock

FOX FLOAT DPS Performance, EVOL LV, 3-position compression lever (Open/Mid/Lock), rebound adjust, trunnion mount, 205mm length x 57.5mm stroke

Fork

RockShox 35 Gold RL, Solo Air spring, low-speed compression adjust to lock, rebound adjust, 35mm steel stanchions, 44mm offset

Fork Travel

150mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

ONOFF Saturn, ACB sealed bearings

Handlebar

ONOFF Sulfur 1.0, double-butted 6061 alloy, 800mm width, 20mm rise, 9° backsweep, 5° upsweep, 31.8mm clamp diameter

Stem

ONOFF Sulfur FG, 6061 forged alloy, 30mm length, 0° rise, 31.8mm bar clamp

Grips

ONOFF Twin, 135mm length, single lock-on

Brakes

SRAM Level T, 2-piston, steel-backed organic pads, SRAM CenterLine one-piece 180mm 6-bolt rotors

Brake Levers

SRAM Level T, Direct Link, lever pivot bushings, tooled reach adjust

Drivetrain

Shifters

SRAM SX Eagle, 12-speed, X-ACTUATION

Front Derailleur

None

Rear Derailleur

SRAM SX Eagle, 12-speed, X-ACTUATION, Type 3 roller bearing clutch

ISCG Tabs

ISCG05

Chainguide

None

Cranks

SRAM SX Eagle DUB
Length: 170mm (SM/MD), 175mm (LG/XL)

Chainrings

SRAM Eagle, 32 tooth, steel, X-SYNC 2, direct mount

Bottom Bracket

SRAM DUB, sealed bearings, 73mm English/BSA threaded

Pedals

None

Chain

SRAM SX Eagle, 12-speed, with PowerLock

Cassette

SRAM SX Eagle PG-1210, 12-speed, 11-50 tooth

Rims

MDK-EP1, 30mm internal width, hookless, 32 hole, tubeless ready

Hubs

Formula, sealed bearings, DC711 15mm x 110mm (Boost) front, DHT148 12mm x 148mm (Boost) rear with HG driver

Spokes

CN round stainless steel

Tires

Front: Maxxis Dissector, 3C MaxxTerra compound, EXO+ casing, TR, 120 TPI, folding bead, 29" x 2.4" WT
Rear: Maxxis Aggressor, Dual compound, EXO casing, TR, 60 TPI, folding bead, 29" x 2.3"

Saddle

MDK series PU

Seatpost

ONOFF Pija dropper, adjustable travel
Drop: 95-125mm (SM), 120-150mm (MD), 140-170mm (LG/XL)

Seatpost Diameter

31.6mm

Seatpost Clamp

Single bolt

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

Bottle Cage Mounts

One inside front triangle

Colors

Gloss Black/Dirty White

Warranty

Lifetime frame with registration

Weight

35 lb 0.9 oz (15,900 g)

Miscellaneous

• Zero Suspension System
• Mondraker Forward Geometry
• Internal cable routing
• SRAM UDH (Universal Derailleur Hanger)
• Includes integrated rear shock mudguard
• UK price: 3199 GBP

Price

$4,799.00
