Specifications

Product

Deviate Claymore Factory Bike

Model Year

2026

Intended Use

Enduro / All-Mountain

Freeride / Bike Park

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	MD	LG	XL
Top Tube Length	592mm	622mm	656mm
Head Tube Angle	64.3°	64.3°	64.3°
Head Tube Length	92mm	108mm	114mm
Seat Tube Angle	78°	78°	78°
Seat Tube Length	410mm	430mm	450mm
Bottom Bracket Height	12mm drop	12mm drop	12mm drop
Chainstay Length	435mm	435mm	435mm
Wheelbase	1233mm	1268mm	1303mm
Reach	460mm	490mm	520mm
Stack	620mm	630mm	640mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 170mm travel fork with 44mm offset

Sizes Additional Info

• Mixed ("Mullet") wheels: 29" front, 27.5" rear

• All specifications listed are with 170mm travel fork with 44mm offset

View Full Geometry

Size	MD	LG	XL
Top Tube Length	592mm	622mm	656mm
Head Tube Angle	64.3°	64.3°	64.3°
Head Tube Length	92mm	108mm	114mm
Seat Tube Angle	78°	78°	78°
Seat Tube Length	410mm	430mm	450mm
Bottom Bracket Height	12mm drop	12mm drop	12mm drop
Chainstay Length	435mm	435mm	435mm
Wheelbase	1233mm	1268mm	1303mm
Reach	460mm	490mm	520mm
Stack	620mm	630mm	640mm
Additional Info	• Mixed ("Mullet") wheels: 29" front, 27.5" rear • All specifications listed are with 170mm travel fork with 44mm offset

Wheel Size

Mixed Wheel Size

Frame Material

Carbon Fiber

Frame Material Details

Carbon front and rear triangles, bolt-on carbon lower down tube protection, bonded rubber chainstay and seatstay protection

Rear Travel

165mm

Rear Shock

FOX FLOAT X2 Factory, Kashima coating, custom tune, 230mm length x 60mm stroke

Fork

FOX FLOAT 38 Factory, GRIP X2 damper, Kashima coating, 44mm offset

Fork Travel

180mm

Head Tube Diameter

Tapered, 1.125" top, 1.5" bottom

Headset

Cane Creek 70, ZS44/28.6 upper, ZS56/40 lower

Handlebar

OneUp Carbon, 800mm width, 35mm clamp diameter

Stem

OneUp, 42mm length, 35mm bar clamp

Grips

Peaty’s Monarch Knurl

Brakes

Shimano XTR M9220, 4-piston
Rotors: Galfer Shark, 220mm front, 203mm rear

Brake Levers

Shimano XTR M9200

Drivetrain

Shifters

Shimano Di2, 12-speed, electronic wireless

Front Derailleur

None

Rear Derailleur

Shimano XTR M9250 Di2, 12-speed, electronic wireless

ISCG Tabs

ISCG05 lower two bolts

Chainguide

18 tooth high-pivot idler pulley and 3-point cover

Cranks

Shimano Deore XT Alloy, 160mm length

Chainrings

Shimano Deore XT, 32 tooth

Bottom Bracket

73mm English/BSA threaded

Pedals

None

Chain

Shimano, 12-speed

Cassette

Shimano, 12-speed, 10-51 tooth

Rims

Reserve Alloy HD

Hubs

OneUp, 15mm x 110mm (Boost) front, 12mm x 148mm (Boost) rear with MICRO SPLINE driver

Spokes

Tires

Front: Continental Kryptotal, Enduro casing, SuperSoft compound, 29" x 2.4"
Front: Continental Kryptotal, Downhill casing, Soft compound, 2.4"

Saddle

SDG Bel-Air V3, Atmos shaping

Seatpost

OneUp V3 dropper

Seatpost Diameter

34.9mm

Seatpost Clamp

Single bolt, 38.5mm

Rear Dropout / Hub Dimensions

12mm x 148mm (Boost)

Max. Tire Size

2.6"

Bottle Cage Mounts

One inside front triangle, plus accessory mounts under top tube

Colors

Oban Sand

Warranty

Lifetime frame and pivot bearings; 2 years paintwork

Weight

Miscellaneous

• High Pivot Point rear suspension design
• Mixed ("Mullet") wheels: 29" front, 27.5" rear; compatible and available with 29" rear wheel
• Cable Gutter external cable routing with internal dropper seatpost routing
• SRAM UDH (Universal Derailleur Hanger)
• Grease ports fitted to all pivot and idler bearings
• Frame weight: 3.2 kg (7.05 lbs)
• Includes OneUp EDC Lite multitool, pre-installed in steerer tube

Price

$8,499.00
