Cannondale

Specifications

Product

Cannondale Trail 1 Bike

Model Year

2025

Intended Use

Cross Country

Rider

Unisex

Sizes and Geometry

View Full Geometry

Size	XS	SM	MD	LG	XL
Top Tube Length	535mm	577mm	609mm	634mm	659mm
Head Tube Angle	68°	68°	68°	68°	68°
Head Tube Length	95mm	95mm	105mm	115mm	125mm
Seat Tube Angle	73.5°	73.5°	73.5°	73.5°	73.5°
Seat Tube Length	330mm	381mm	432mm	470mm	533mm
Bottom Bracket Height	293mm (60mm drop)	293mm (60mm drop)	307mm (65mm drop)	307mm (65mm drop)	307mm (65mm drop)
Chainstay Length	440mm	440mm	445mm	445mm	445mm
Wheelbase	1054mm	1098mm	1140mm	1166mm	1192mm
Standover	673mm	710mm	768mm	795mm	839mm
Reach	365mm	402mm	425mm	447mm	469mm
Stack	573mm	591mm	623mm	632mm	641mm
Additional Info	• XS/SM have 27.5" wheels; MD-XL have 29" wheels • XS/SM specifications listed are with 80mm travel fork with 42mm offset • MD-XL specifications listed are with 100mm travel fork with 46mm offset

Sizes Additional Info

• XS/SM have 27.5" wheels; MD-XL have 29" wheels
• XS/SM specifications listed are with 80mm travel fork with 42mm offset
• MD-XL specifications listed are with 100mm travel fork with 46mm offset

View Full Geometry

Size	XS	SM	MD	LG	XL
Top Tube Length	535mm	577mm	609mm	634mm	659mm
Head Tube Angle	68°	68°	68°	68°	68°
Head Tube Length	95mm	95mm	105mm	115mm	125mm
Seat Tube Angle	73.5°	73.5°	73.5°	73.5°	73.5°
Seat Tube Length	330mm	381mm	432mm	470mm	533mm
Bottom Bracket Height	293mm (60mm drop)	293mm (60mm drop)	307mm (65mm drop)	307mm (65mm drop)	307mm (65mm drop)
Chainstay Length	440mm	440mm	445mm	445mm	445mm
Wheelbase	1054mm	1098mm	1140mm	1166mm	1192mm
Standover	673mm	710mm	768mm	795mm	839mm
Reach	365mm	402mm	425mm	447mm	469mm
Stack	573mm	591mm	623mm	632mm	641mm
Additional Info	• XS/SM have 27.5" wheels; MD-XL have 29" wheels • XS/SM specifications listed are with 80mm travel fork with 42mm offset • MD-XL specifications listed are with 100mm travel fork with 46mm offset

Wheel Size

27.5" (650b)

29"

Frame Material

Aluminum

Frame Material Details

SmartForm C3 Alloy

Rear Travel

Hardtail

Rear Shock

None

Fork

SR Suntour XCM, coil spring

Fork Travel

XS/SM: 80mm; MD-XL: 100mm

Head Tube Diameter

Straight, 1.125"

Headset

Semi-Integrated

Handlebar

Cannondale Riser, 6061 alloy, 720mm width, 25mm rise, 8° sweep, 6° rise, 31.8mm clamp diameter

Stem

Cannondale 4, 6061 alloy, 6° rise, 31.8mm bar clamp

Grips

Cannondale

Brakes

Tektro M275, 2-piston
Rotors: Tektro, 160mm

Brake Levers

Tektro M275

Drivetrain

Shifters

Shimano CUES U6000, 10-speed

Front Derailleur

None

Rear Derailleur

Shimano CUES U6000, 10-speed

ISCG Tabs

None

Chainguide

None

Cranks

Prowheel Charm

Chainrings

Prowheel Charm, 30 tooth

Bottom Bracket

Prowheel, square taper, 73mm English/BSA threaded

Pedals

None

Chain

KMC X10, 10-speed

Cassette

Shimano CUES, 10-speed, 11-48 tooth

Rims

WTB SX19 Alloy, 32 hole

Hubs

Shimano TC500, 15mm x 110mm (Boost) front, 12mm x 142mm rear with HG driver

Spokes

Stainless steel, 14g

Tires

WTB Ranger, 2.25"

Saddle

Cannondale Trail

Seatpost

JD dropper, 130mm drop

Seatpost Diameter

31.6mm

Seatpost Clamp

Quick release

Rear Dropout / Hub Dimensions

12mm x 142mm

Max. Tire Size

Bottle Cage Mounts

Two inside front triangle

Colors

Black, Tiger Shark, Tungsten Blue

Warranty

Lifetime frame, 1 year Cannondale components and paint/decals

Weight

Miscellaneous

• XS/SM have 27.5" wheels; MD-XL have 29" wheels
• StraightShot internal cable routing
• Rack and fender mounts
• KickFlip hidden 18mm 2-bolt kickstand mount

Price

$950.00
