Santa Cruz Superlight Frame (discontinued)

Views:
Discontinued
2015 Santa Cruz Superlight - blue
 Santa Cruz Superlight Frame  Santa Cruz Superlight Frame
Create New Tag

Compare to other Frames

Need more info? View our Cross Country Mountain Bike Frames buyer's guide.

Specifications

Product Santa Cruz Superlight Frame
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
S (27.5"), M (27.5"), L (29"), XL (29") View Geometry
Size S (27.5") M (27.5") L (29") XL (29")
Top Tube Length 22.2" 23.23" 24.13" 25.12"
Head Tube Angle 69° 69° 70.2° 70.2°
Head Tube Length 3.54" 3.94" 3.94" 4.33"
Seat Tube Angle 73° 73° 72.7° 72.7°
Seat Tube Length 16.22" 17.52" 19.49" 20.98"
Bottom Bracket Height 13.03" 13.03" 13.31" 13.31"
Chainstay Length 16.69" 16.69" 17.48" 17.48"
Wheelbase 42.17" 43.19" 43.86" 44.88"
Standover 27.2" 27.36" 29.41" 29.8"
Reach 15.24" 16.14" 16.57" 17.48"
Stack 22.8" 23.15" 24.17" 24.57"
Wheel Size 27.5" (650b), 29"
Frame Material Aluminum
Frame Material Details Full Aluminum
Rear Travel 100mm
Rear Shock FOX Float CTD
Head Tube Diameter Mixed Taper 1.5" Lower, 1-1/8" Upper
Bottom Bracket Standard 73mm Threaded
Rear Dropout / Hub Dimensions 142mm x 12mm Through-Axle, Includes a DT RWS Axle
Front Derailleur Size 34.9mm Top Swing (Low-Clamp) Top Pull
Seatpost Diameter 30.9mm
Max Tire Size 2.3" x 27.5" on Sizes S and M / 29" on Sizes L and XL
ISCG Tabs N/A
Bottle Cage Mounts Yes
Colors Dark Blue and Gloss Green, Red and White
Warranty Five Year Frame, Lifetime Bearing
Weight N/A
Miscellaneous Fork Compatibility: 100-120mm
Price $1,099
