Specifications

Product Pivot Point Frame
Riding Type Dirt Jump / Slopestyle
Rider Unisex
Sizes and Geometry
Size MD
Top Tube Length 605mm
Head Tube Angle 68.50°
Head Tube Length 110mm
Seat Tube Angle 72.0°
Seat Tube Length 320mm
Bottom Bracket Height 325mm
Chainstay Length 385-400mm
Wheelbase 1060.5mm
Standover
Reach 425.9mm
Stack 551.3mm
Wheel Size 26"
Frame Material Chromoly
Frame Material Details Double-butted 4130 chromoly
Rear Travel Hardtail
Rear Shock N/A
Head Tube Diameter Tapered, uses an integrated style headset (top IS42 (45°), bottom IS52/40)
Bottom Bracket Threaded 73mm
Rear Dropout / Hub Dimensions 10x135mm vertical dropouts
Front Derailleur Size N/A
Seatpost Diameter 27.2mm (29.8mm single bolt clamp included)
Max Tire Size 26" x 2.3"
ISCG Tabs ISCG 05
Bottle Cage Mounts No
Colors Mojave
Warranty 3 years
Weight N/A
Miscellaneous • 2021 model year release
• Geometry features long reach and ultra-short chainstays
• Dropouts included for running with gears and a derailleur hanger or singlespeed
• Cable routing for geared or singlespeed builds
• Designed for either a 100mm or 120mm fork (130mm max)
• 50mm chainline and 172mm minimum Q factor
• Secure chain-tension adjustment system with chainstay adjustment range of 385-400mm
• Available as a one-size-fits-most (fitting riders between 5’ and 6’4”)
Price $599
