Pivot M4X Frame

Views:
Create New Tag

Compare to other Frames

Specifications

Product Pivot M4X Frame
Riding Type Dirt Jump / Slopestyle, Other (4x/slalom)
Rider Unisex
Sizes and Geometry
Size S L
Top Tube Length 566.4mm 596.9mm
Head Tube Angle 67.5° 67.5°
Head Tube Length 114.3mm 114.3mm
Seat Tube Angle 72° 72°
Seat Tube Length 381mm 381mm
Bottom Bracket Height 317.5mm 317.5mm
Chainstay Length 419.1mm 419.1mm
Wheelbase 1069.3mm 1099.8mm
Standover 647.7mm 647.7mm
Reach 389.4mm 419.9mm
Stack 545.1mm 545.1mm
Wheel Size 26"
Frame Material Aluminum
Frame Material Details
Rear Travel 100mm
Rear Shock FOX Float Adaptive Logic RP23, Kashima
Head Tube Diameter Tapered, ZS44mm /ZS56mm
Bottom Bracket Threaded 73mm
Rear Dropout / Hub Dimensions 12mm x 142mm, DT Swiss axle included
Front Derailleur Size 1x only
Seatpost Diameter 30.9mm, 34.9mm quick release
Max Tire Size 2.3"
ISCG Tabs ISCG05
Bottle Cage Mounts No
Colors Night Black
Warranty 3 year
Weight N/A
Miscellaneous Dropper post compatible
Fork travel of 100-120mm recommended
Price N/A
