2018 Pivot Shuttle US/CAN E-Bike (discontinued)

Pivot Shuttle
2018 Pivot Shuttle US/CAN E-Bike 2018 Pivot Shuttle US/CAN E-Bike 2018 Pivot Shuttle US/CAN E-Bike 2018 Pivot Shuttle US/CAN E-Bike 2018 Pivot Shuttle US/CAN E-Bike
Create New Tag

Compare to other E-Bikes


Product Pivot Shuttle US/CAN E-Bike
Model Year 2018
Riding Type Enduro / All-Mountain, Trail
Rider Unisex
Sizes and Geometry
S, M, L, XL View Geometry
Size S M L XL
Top Tube Length 597.9mm 620.5mm 643.1mm 670.6mm
Head Tube Angle 65.8° 65.8° 65.8° 65.8°
Head Tube Length 110mm 119.9mm 130mm 140mm
Seat Tube Angle 74° 74° 74° 74°
Seat Tube Length 393.7mm 425.5mm 457.2mm 495.3mm
Bottom Bracket Height 348mm 348mm 348mm 348mm
Chainstay Length 436.9mm 436.9mm 436.9mm 436.9mm
Wheelbase 1184.4mm 1208.5mm 1232.7mm 1261.9mm
Standover 705.6mm 705.6mm 712.7mm 716.5mm
Reach 424.9mm 445mm 465.1mm 490mm
Stack 602.7mm 611.9mm 621mm 630.2mm
* Additional Info Measured with 150mm fork
Wheel Size 27.5+
E-Bike Class Class 1: Pedal Assist (Pedelecs)
Motor Shimano Steps E8000
Battery Shimano BT-E8010
Battery Capacity 500 Wh
Display/Remote System controls and power modes are accessible from handlebar actuated levers and Shimano display.
Display screen: battery level indicator, gear position, assist gauge, assist mode, and display mode (distance, odometer, range, travel time, current speed, average speed, max speed, cadence, watts, calories, or clock)
Modes Eco, Trail, Boost, and Walk
Max Speed with Assist 20 mph (32 km/h)
Frame Material Carbon Fiber
Frame Material Details Full carbon frame with molded composite motor casing and skid plate
Rear Travel 140mm
Rear Shock FOX Float Performance Elite DPX2
Fork FOX 36 Performance Elite 29"/27.5+, Boost
Fork Travel 150mm
Head Tube Diameter Tapered
Headset Pivot Precision Sealed Cartridge
Handlebar Phoenix Team Carbon, 35mm diameter, 760mm width
Stem Phoenix Team Enduro, 35mm clamp, 45mm length
Grips Phoenix Team Padloc
Brakes Shimano XT M8020, 4-piston
Brake Levers Shimano XT M8020
Drivetrain 1x
Shifters Shimano XT Di2 11-speed (right) / Shimano Steps E8000 (left)
Front Derailleur N/A
Rear Derailleur Shimano XT Di2 GS
Chainguide N/A
Cranks Shimano FC-E8050 Hollowtech, 170mm length
Chainrings 34 tooth
Pedals N/A
Chain 11-speed
Cassette Shimano XT M8000, 11-46 tooth, 11-speed
Rims DT Swiss/Pivot Custom EB1550 eMTB specific design, 40mm width
Hubs DT Swiss/Pivot Custom EB1550 eMTB specific design
Spokes DT Swiss/Pivot Custom EB1550 eMTB specific design
Tires Front: Maxxis Minion DHF, 27.5+ x 2.8" TR
Rear: Maxxis Rekon 27.5+ x 2.8" TR/Silk Shield
Saddle Phoenix WTB Hightail Trail Race (S), Phoenix WTB Vigo Pro (M-XL)
Seatpost FOX Transfer, 125mm drop (S), 150mm drop (M-XL)
Seatpost Diameter 30.9mm
Seatpost Clamp Standard single bolt, 34.9mm clamp
Rear Dropout / Hub Dimensions Super Boost Plus, 12mm x 157mm
Max. Tire Size 27.5+ up to 3"
29" up to 2.5"
Bottle Cage Mounts No
Colors Sterling Silver
Warranty 10-year frame
Weight N/A
Miscellaneous Dw-link rear suspension with Pivot’s mid-travel e-MTB specific linkage design
27.5”+ with 29” compatibility
Pivot Cable Port system for easy internal routing of shifters, brakes, and droppers
Full Di2 Integration
Automotive quality gaskets with externally accessible charging ports
Ultra-quiet, low durometer rubberized frame and skid-plate protection
Compatible with 150mm or 160mm forks
Settings are customizable via Shimano‘s E-tube project smart phone app
Available in S, M, L, and XL to fit riders from 162 to 200cm (5’4” to 6’7”+)
Price $9,999
