2020 Trek X-Caliber 7 Bike

Views:
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product Trek X-Caliber 7 Bike
Model Year 2020
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
S, M, ML, L, XL View Geometry
Size S M ML L XL
Top Tube Length 555 601 617 637 658
Head Tube Angle 69.3° 69.5° 69.5° 69.5° 69.5°
Head Tube Length 90 90 90 100 120
Seat Tube Angle 73.5° 73° 73° 73° 73°
Seat Tube Length 368 419 444 470 521
Bottom Bracket Height 302 (-48 drop) 311 (-58 drop) 310 (-58 drop) 310 (-58 drop) 310 (-58 drop)
Chainstay Length 425 438 438 438 438
Wheelbase 1053 1109 1125 1145 1167
Standover 724 748 757 757 768
Reach 385 418 434 451 466
Stack 574 598 598 608 626
* Additional Info All measurements are in mm unless otherwise noted.
29" wheels on all sizes except size and S which has 27.5" wheels.
Wheel Size 29", 27.5" (650b)
Frame Material Aluminum
Frame Material Details Alpha Gold Aluminum
Rear Travel Hardtail
Rear Shock N/A
Fork RockShox 30 Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, tapered steerer, 42mm offset on S, 46mm offset on M-XL, 100mm quick release
Fork Travel 100mm
Head Tube Diameter Tapered 1.125-1.5"
Headset Semi-integrated, cartridge bearing
Handlebar Bontrager alloy, 31.8mm, 5mm rise, 720mm width
Stem Bontrager Elite, 31.8mm, Blendr compatible, 7°, 60mm on S, 70mm on M/ML, 80mm on L, 90mm on XL
Grips Bontrager XR Trail Comp, nylon lock-on
Brakes Shimano MT200 hydraulic disc
Brake Levers Shimano MT201
Drivetrain 2x
Shifters Shimano Acera M3000, 2 x 9-speed
Front Derailleur Shimano Alivio M4020, e-type, side swing, front pull
Rear Derailleur Shimano Alivio M4000, long cage, 36 tooth max cog
ISCG Tabs None
Chainguide None
Cranks Shimano MT210, Boost, 170mm on S, 175mm on M/ML/L/XL
Chainrings 36 and 22 tooth
Bottom Bracket 73mm, threaded
Pedals VP-536, nylon platform
Chain KMC X9, 9-speed
Cassette Shimano HG200, 11-36 tooth, 9-speed
Rims Bontrager Connection, double-wall, 20mm width, 32 hole, presta valve
Hubs Front: Formula DC-20, alloy, 6-bolt, 5mm x 100mm quick release
Rear: Formula DC-2241, alloy, 6-bolt, Shimano 8/9/10 freehub, Boost141, 5mm quick release
Spokes
Tires Bontrager XR2 Comp, wire bead, 30 TPI, 2.20"
Saddle Bontrager Arvada, steel rails, 138mm width
Seatpost Bontrager alloy, 12mm offset
Seatpost Diameter 31.6mm
Seatpost Clamp Quick release
Rear Dropout / Hub Dimensions Boost 5mm x 141mm, quick release
Max. Tire Size
Bottle Cage Mounts Yes
Colors Radioactive Red
Warranty Lifetime frame
Weight 30 lb 6.8 oz (13,800 g)
Miscellaneous Size S has 27.5" wheels
Sizes M/ML/L/XL has 29" wheels
Weight given for size M, with inner tubes
Total 300lb weight limit
Internal derailleur and dropper post routing
Rack and kickstand mounts
Price $1,019.99
