2020 Trek Top Fuel 9.7 Bike

Views:
2020 Trek Top Fuel 9.7 in Trek Black to Teal Fade
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product Trek Top Fuel 9.7 Bike
Model Year 2020
Riding Type Trail
Rider Unisex
Sizes and Geometry
S, M, M/L, L, XL View Geometry
Size S M M/L L XL
Top Tube Length 563, 564 598, 599 614, 615 630, 632 650, 651
Head Tube Angle 68° High, 67.5° Low 68° High, 67.5° Low 68° High, 67.5° Low 68° High, 67.5° Low 68° High, 67.5° Low
Head Tube Length 90 90 90 100 110
Seat Tube Angle 75.5°, 75.0° 75.5°, 75.0° 75.5°, 75.0° 75.5°, 75.0° 75.5°, 75.0°
Seat Tube Length 394 419 445 470 521
Bottom Bracket Height 343, 337 343, 337 343, 337 343, 337 343, 337
Chainstay Length 434, 435 434, 435 434, 435 434, 435 434, 435
Wheelbase 1117 1152 1168 1185, 1186 1185, 1186
Standover 730, 725 735, 730 741, 735 751, 745 771, 765
Reach 410, 405 445, 440 461, 456 475, 470 492, 487
Stack 590, 594 590, 594 590, 594 599, 603 608, 612
* Additional Info All dimensions in mm unless noted otherwise. Geometry is based on 120mm fork. High, low positions given.
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details OCLV Mountain Carbon main frame and stays, Knock Block , internal cable routing, Carbon Armor, magnesium rocker link, Mino Link, ABP
Rear Travel 115mm
Rear Shock FOX Performance Float, 2-position DPS damper, TwistLoc remote, tuned by Trek Suspension Lab, 190x45mm
Fork RockShox Reba RL, Solo Air spring, Motion Control damper, TwistLoc remote, 46mm offset, 110x15mm Maxle Stealth
Fork Travel 120mm
Head Tube Diameter Tapered 1.125-1.5"
Headset Sealed tapered 1.125"-1.5" cartridge bearing with Knock Block
Handlebar Bontrager Comp, aluminum, 31.8mm clamp, 15mm rise
Stem Bontrager Rhythm Comp, Knock Block compatible, 31.8mm clamp, 0 degree rise/drop (60mm on sizes S-M/L, 70mm on sizes L-XL)
Grips SRAM TwistLoc remote
Brakes Shimano MT500
Brake Levers Shimano MT501
Drivetrain 1x
Shifters SRAM NX Eagle 12-speed
Front Derailleur None
Rear Derailleur SRAM NX Eagle 12-speed
ISCG Tabs None
Chainguide None
Cranks SRAM NX Eagle DUB
Chainrings SRAM Eagle 32 tooth steel ring, Boost chainline
Bottom Bracket SRAM DUB BB92
Pedals
Chain SRAM NX Eagle 12-speed
Cassette SRAM PG-1230 Eagle, 11-50 tooth, 12-speed
Rims Bontrager Kovee Comp 23, Tubeless Ready
Hubs Bontrager 6-bolt, 110x15mm front and 148x12mm rear
Spokes Bontrager Comp OEM
Tires Bontrager XR3 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120tpi, 29x2.40"
Saddle Bontrager Montrose Comp, steel rails
Seatpost Bontrager Line Dropper, internal routing
Seatpost Diameter 31.6mm
Seatpost Clamp bolt-on
Rear Dropout / Hub Dimensions Boost 148x12mm
Max. Tire Size
Bottle Cage Mounts Yes (downtube)
Colors Trek Black to Teal Fade and Metallic Gunmetal/Dnister Black
Warranty Lifetime frame, five year swingarm warranty
Weight 27 lb 13.5 oz (12,630 g)
Miscellaneous - Weight given for size M, with inner tubes
- Total 300lb weight limit
- Optional Trek top-only chainguide
- 1x only
- 100mm dropper clearance on size S, 150mm on size M-M/L, 170mm on L-2XL
- Includes Knock Block anti-fork rotation protection
Price $3,999.99
