2022 Trek Slash 9.8 XT Bike

Views:
2022 Trek Slash 9.8 XT (Matte Battleship Blue)
2022 Trek Slash 9.8 XT Bike 2022 Trek Slash 9.8 XT Bike 2022 Trek Slash 9.8 XT Bike
Create New Tag

Compare to other Bikes

Specifications

Product Trek Slash 9.8 XT Bike
Model Year 2022
Riding Type Enduro / All-Mountain, Freeride / Bike Park
Rider Unisex
Sizes and Geometry
SM (High, Low), MD (High, Low), ML (High, Low), LG (High, Low), XL (High, Low) View Geometry
Size SM (High, Low) MD (High, Low) ML (High, Low) LG (High, Low) XL (High, Low)
Top Tube Length 584mm, 585mm 609mm, 610mm 628mm, 629mm 647mm, 649mm 683mm, 684mm
Head Tube Angle 64.6°, 64.1° 64.6°, 64.1° 64.6°, 64.1° 64.6°, 64.1° 64.6°, 64.1°
Head Tube Length 100mm 100mm 105mm 115mm 140mm
Seat Tube Angle 76.1°, 75.6° 76.1°, 75.6° 76.1°, 75.6° 76.1°, 75.6° 76.1°, 75.6°
Seat Tube Length 395mm 420mm 435mm 450mm 500mm
Bottom Bracket Height 352mm (22mm drop), 345mm (29mm drop) 352mm (22mm drop), 345mm (29mm drop) 352mm (22mm drop), 345mm (29mm drop) 352mm (22mm drop), 345mm (29mm drop) 352mm (22mm drop), 345mm (29mm drop)
Chainstay Length 435mm, 437mm 435mm, 437mm 435mm, 437mm 435mm, 437mm 435mm, 437mm
Wheelbase 1197mm, 1197mm 1212mm, 1222mm 1242mm, 1243mm 1263mm, 1264mm 1304mm, 1305mm
Standover 711mm, 705mm 749mm, 743mm 749mm, 743mm 759mm, 753mm 779mm, 773mm
Reach 431mm, 425mm 456mm, 450mm 474mm, 469mm 491mm, 486mm 521mm, 516mm
Stack 618mm, 621mm 618mm, 622mm 622mm, 626mm 631mm, 635mm 654mm, 658mm
* Additional Info Geometry adjustable via Mino Link flip chip in rear rocker link pivot
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details OCLV Mountain Carbon main frame and stays; magnesium rocker link; carbon armor molded down tube, seatstay, and chainstay protection
Rear Travel 160mm
Rear Shock RockShox Super Deluxe Ultimate, DebonAir spring, Thru-Shaft 3-position damper, 230mm x 62.5mm
Fork RockShox ZEB Select+, DebonAir spring, Charger 2.1 RC damper, 38mm stanchions, 44mm offset, Maxle Stealth axle
Fork Travel 170mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Trek Knock Block 2.0 Integrated, 72° radius (includes infinite radius chip), sealed cartridge bearings
Handlebar Bontrager Line Pro, OCLV Carbon, 820mm width, 27.5mm rise, 35mm clamp diameter
Stem Bontrager Line Pro, 35mm length, 0° rise, 35mm bar clamp, Knock Block and Blendr compatible
Grips Bontrager XR Trail Pro, alloy lock-on
Brakes Shimano Deore XT M8120, 4-piston, Shimano RT76 6-bolt rotors (203mm front, 180mm rear)
Brake Levers Shimano Deore XT M8120
Drivetrain 1x
Shifters Shimano Deore XT M8100, 12-speed
Front Derailleur None
Rear Derailleur Shimano Deore XT M8100, 12-speed, long cage
ISCG Tabs ISCG05
Chainguide MRP upper slider with bashguard
Cranks Shimano Deore XT M8120, 170mm length
Chainrings Shimano Deore XT M8120, 30 tooth
Bottom Bracket Shimano BB52, 73mm English/BSA theaded
Pedals None
Chain Shimano Deore XT M8100, 12-speed
Cassette Shimano Deore XT M8100, 12-speed, 10-51 tooth
Rims Bontrager Line Elite 30, OCLV Mountain Carbon, tubeless ready
Hubs Bontrager Line Elite 30 wheelset, sealed bearings, 110x15mm Boost front, 148x12mm Boost rear with Rapid Drive 108 freehub and MICRO SPLINE driver
Spokes Bontrager Line Elite 30 wheelset
Tires Front: Bontrager SE6 Team Issue, tubeless ready, Core Strength sidewalls, aramid bead, 120 TPI, 29" x 2.5"
Rear: Bontrager SE5 Team Issue, tubeless ready, Core Strength sidewalls, aramid bead, 120 TPI, 29" x 2.5"
Saddle Bontrager Arvada, austenite rails, 138mm width
Seatpost Bontrager Line Elite dropper, MaxFlow
Drop: 100mm (SM), 150mm (MD/ML), 170mm (LG), 200mm (XL)
Seatpost Diameter 34.9mm
Seatpost Clamp Single bolt
Rear Dropout / Hub Dimensions 148x12mm Boost
Max. Tire Size 29" x 2.5"
Bottle Cage Mounts One inside front triangle
Colors Lithium Grey, Matte Battleship Blue, Radioactive Coral to Yellow Fade
Warranty Lifetime frame and wheels; 2 years Trek/Bontrager parts, suspension linkage components, and paint/decals
Weight 32 lb 1.6 oz (14,560 g)
Miscellaneous • ABP (Active Braking Pivot) suspension system
• Geometry adjustable via Mino Link flip chip in rear rocker link pivot
• Knock Block 2.0 steerer stop
• Internal frame storage via quick-access latch under bottle cage mounts
• Control Freak internal cable routing
• Includes Bontrager BITS internal frame storage bag
• Includes Bontrager TLR rim strips, tubeless valves, and sealant
Price
  • $5,999.99
  • $6,499.99
