2020 Trek Slash 9.8 XT Bike (discontinued)

Views:
Discontinued
2020 Trek Slash 9.8 XT Gloss Purple Phaze Matte Raw Carbon
2020 Trek Slash 9.8 XT Bike 2020 Trek Slash 9.8 XT Bike 2020 Trek Slash 9.8 XT Bike
Related: Trek
Trek
Edit Tags Done
Create New Tag
Edit Tags Done

Compare to other Bikes

Need more info? View our Enduro / All-Mountain Mountain Bikes buyer's guide.

Specifications
Product Trek Slash 9.8 XT Bike
Model Year 2020
Riding Type Enduro / All-Mountain
Rider Unisex
Sizes and Geometry
S (High), S (Low), M (High), M (Low), L (High), L (Low), XL (High), XL (Low) View Geometry
Size S (High) S (Low) M (High) M (Low) L (High) L (Low) XL (High) XL (Low)
Top Tube Length 589 591 604 606 635 637 661 663
Head Tube Angle 65.6° 65.1° 65.6° 65.1° 65.6° 65.1° 65.6° 65.1°
Head Tube Length 100 100 100 100 110 110 125 125
Seat Tube Angle 74.1° 73.6° 74.1° 73.6° 74.1° 73.6° 74.1° 73.6°
Seat Tube Length 394 394 419 419 470 470 521 521
Bottom Bracket Height 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop)
Chainstay Length 433 435 433 435 433 435 433 435
Wheelbase 1171 1172 1186 1187 1219 1219 1247 1248
Standover 757 751 759 753 770 764 781 775
Reach 416 410 431 425 459 453 481 475
Stack 608 612 608 612 618 622 631 635
* Additional Info All measurements are in mm unless otherwise noted. High and Low refers to the position on the Mino Link.
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details OCLV Mountain Carbon main frame and stays, Carbon Armor, magnesium rocker link
Rear Travel 150mm
Rear Shock RockShox Deluxe RT3, RE:aktiv with Thru Shaft 3-position damper, tuned by Trek Suspension Lab, 230x57.5 mm
Fork RockShox Lyrik Select+, DebonAir spring, Charger 2 RC damper, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth
Fork Travel 160mm
Head Tube Diameter Tapered 1.125-1.5"
Headset Knock Block Integrated, cartridge bearing
Handlebar Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 820mm width
Stem Bontrager Line Pro, 35mm, Knock Block, 0°, 50mm length
Grips Bontrager XR Trail Elite, alloy lock-on
Brakes Shimano SLX M7120, 4-piston, hydraulic disc, Shimano RT66 6-bolt rotors, 180mm rear, 203mm front
Brake Levers Shimano SLX
Drivetrain 1x
Shifters Shimano XT M8100, 12-speed
Front Derailleur None
Rear Derailleur Shimano XT M8100, long cage, 51 tooth max cog, 12-speed
ISCG Tabs ISCG 05
Chainguide Yes
Cranks Shimano XT M8100, Boost, 170mm on S, 175mm on M/L/XL
Chainrings 32 tooth, alloy
Bottom Bracket Shimano MT500, 92mm, press-fit
Pedals None
Chain Shimano XT M8100, 12-speed
Cassette Shimano XT M8100, 10-51 tooth, 12-speed
Rims Bontrager Line Carbon 30, tubeless ready
Hubs Front: Bontrager, 6-bolt, Boost110
Rear: Bontrager, 54 tooth Rapid Drive, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle
Spokes
Tires Front: Bontrager SE5 Team Issue, tubeless ready, Core Strength sidewall, aramid bead, 60 TPI, 29x2.60"
Rear: Bontrager SE4 Team Issue, tubeless ready, Core Strength sidewalls, aramid bead, 60 TPI, 29x2.4"
Saddle Bontrager Arvada, austenite rails, 138mm width
Seatpost Bontrager Line Elite Dropper, internal routing, 100mm on S, 130mm on M, 150mm on L, 170mm on XL
Seatpost Diameter 31.6mm
Seatpost Clamp Standard single bolt
Rear Dropout / Hub Dimensions 12mm x 148mm
Max. Tire Size
Bottle Cage Mounts Yes
Colors Matte Carbon/Voodoo Trek Black
Cobra Blood to Magenta Flip
Gloss Purple Phaze/Matte Raw Carbon
Warranty Lifetime frame, five year swingarm warranty
Weight N/A
Miscellaneous Weight given for size M, with inner tubes
Total 300lb weight limit
Active Braking Pivot
Knock Block anti-fork rotation protection
Mino Link adjustable geometry
Control Freak internal routing
Gloss Purple Phaze/Matte Raw Carbon color costs an extra $500
Price $5,899.99
