2020 Trek Slash 8 Bike

Views:
2020 Trek Slash 8 Cobra Blood to Magenta Flip
2020 Trek Slash 8 Bike 2020 Trek Slash 8 Bike 2020 Trek Slash 8 Bike
Create New Tag

Compare to other Bikes

Need more info? View our Enduro / All-Mountain Mountain Bikes buyer's guide.

Specifications

Product Trek Slash 8 Bike
Model Year 2020
Riding Type Enduro / All-Mountain
Rider Unisex
Sizes and Geometry
S (High), S (Low), M (High), M (Low), ML (High), ML (Low), L (High), L (Low), XL (High), XL (Low) View Geometry
Size S (High) S (Low) M (High) M (Low) ML (High) ML (Low) L (High) L (Low) XL (High) XL (Low)
Top Tube Length 580 582 595 597 611 613 626 627 651 653
Head Tube Angle 65.6° 65.1° 65.6° 65.1° 65.6° 65.1° 65.6° 65.1° 65.6° 65.1°
Head Tube Length 100 100 100 100 105 105 110 110 125 125
Seat Tube Angle 74.9° 74.4° 74.9° 74.4° 74.9° 74.4° 74.9° 74.4° 74.9° 74.4°
Seat Tube Length 394 394 419 419 445 445 470 470 521 521
Bottom Bracket Height 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop) 352 (-21 drop) 345 (-28 drop)
Chainstay Length 433 435 433 435 433 435 433 435 433 435
Wheelbase 1171 1172 1186 1187 1203 1204 1219 1219 1247 1248
Standover 746 740 759 753 765 759 770 764 780 774
Reach 416 410 431 425 446 440 459 453 481 475
Stack 608 612 608 612 613 617 618 622 631 635
* Additional Info Measurements are in mm unless otherwise noted. High and Low refers to the position on the Mino Link.
Wheel Size 29"
Frame Material Aluminum
Frame Material Details Alpha Platinum Aluminum, magnesium rocker link, down tube guard
Rear Travel 150mm
Rear Shock RockShox Deluxe RT3, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 230x57.5mm
Fork RockShox Yari RC, DebonAir, Motion Control RC damper, tapered steerer, Boost110, G2 Geometry with 42mm offset
Fork Travel 160mm
Head Tube Diameter Tapered 1.125-1.5"
Headset Knock Block Integrated, cartridge bearing
Handlebar Bontrager Line, alloy, 35mm, 27.5mm rise
Stem Bontrager Line, 35mm clamp, Knock Block, 0°
Grips Bontrager XR Trail Elite, alloy lock-on
Brakes Front: SRAM Guide R, hydraulic disc, SRAM CenterLine 6-bolt round-edge 200mm rotor
Rear: SRAM Guide R, hydraulic disc, SRAM CenterLine 6-bolt round-edge 180mm rotor
Brake Levers SRAM Guide R
Drivetrain 1x
Shifters SRAM GX Eagle, 12-speed
Front Derailleur None
Rear Derailleur SRAM GX Eagle, 12-speed, roller bearing clutch
ISCG Tabs ISCG 05
Chainguide None
Cranks SRAM Truvativ Descendant 6k Eagle, DUB
Chainrings 32 tooth, direct mount
Bottom Bracket SRAM DUB, 92mm, press fit
Pedals None
Chain SRAM GX Eagle, 12-speed
Cassette SRAM XG-1275 Eagle, 10-50 tooth, 12-speed
Rims Bontrager Line Comp 30, tubeless ready
Hubs Front: Bontrager Boost110
Rear: Bontrager, 54 tooth Rapid Drive, Boost148, 12mm thru axle
Spokes DT Swiss Champion, 20-007, stainless steel, J-bend
Tires Front: Bontrager SE5 Team Issue, tubeless ready, Core Strength sidewall, aramid bead, 60 tpi, 29x2.60"
Rear: Bontrager SE4 Team Issue, tubeless ready, Core Strength sidewalls, aramid bead, 60 tpi, 29x2.4"
Saddle Bontrager Arvada, hollow chromoly rails
Seatpost Bontrager Line Dropper, internal routing
Seatpost Diameter 31.6mm
Seatpost Clamp Standard single bolt
Rear Dropout / Hub Dimensions Boost 12x148mm
Max. Tire Size
Bottle Cage Mounts Yes
Colors Matte Trek Black
Miami to Volt Fade
Cobra Blood to Magenta Flip
Warranty Lifetime frame, five year swingarm warranty
Weight 31 lb 4.9 oz (14,200 g)
Miscellaneous Weight given for size M, with inner tubes
Total 300lb weight limit
Active Braking Pivot
Knock Block anti-fork rotation protection
Mino Link adjustable geomery
Control Freak internal routing
Price $3,699.99
