2018 Trek Fuel EX 8 29 Bike (discontinued)

Views:
Discontinued
2018_Trek_Fuel_EX_8_29
Related: Trek
Trek
Edit Tags Done
Create New Tag
Edit Tags Done

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications
Product Trek Fuel EX 8 29 Bike
Model Year 2018
Riding Type Trail
Rider Unisex
Sizes and Geometry
15.5 in., 17.5 in., 18.5 in., 19.5 in., 21.5 in., 23 in. View Geometry
Size 15.5 in. 17.5 in. 18.5 in. 19.5 in. 21.5 in. 23 in.
Top Tube Length 565mm 600mm 617mm 632mm 657mm 686mm
Head Tube Angle 67.7° 67.7° 67.7° 67.7° 67.7° 67.7°
Head Tube Length 100mm 100mm 100mm 100mm 110mm 145mm
Seat Tube Angle 74.7° 74.7° 74.7° 74.7° 74.7° 74.7°
Seat Tube Length 394mm 419mm 440mm 470mm 510mm 560mm
Bottom Bracket Height 344mm 344mm 344mm 344mm 344mm 344mm
Chainstay Length 432mm 432mm 432mm 432mm 432mm 432mm
Wheelbase 1121mm 1156mm 1173mm 1188mm 1214mm 124.7mm
Standover 767mm 747mm 742mm 737mm 747mm 787mm
Reach 399mm 433mm 450mm 465mm 487mm 507mm
Stack 604mm 603mm 603mm 603mm 612mm 64.4mm
* Additional Info All specifications listed are for "High" geometry position.
Wheel Size 29"
Frame Material Aluminum
Frame Material Details Alpha Platinum aluminum, down tube guard
Rear Travel 130mm
Rear Shock FOX Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 210mm x 52.5mm
Fork FOX Rhythm 34 Float, GRIP adjustable damper, E2 tapered steerer, G2 Geometry, 51mm offset, Boost110
Fork Travel 130mm
Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
Headset Knock Block Integrated, sealed cartridge bearing
Handlebar Bontrager Line, 35mm clamp, 15mm rise, 750mm width
Stem Bontrager Line, Knock Block, 35mm clamp, 0° rise, 60mm length
Grips Bontrager Race Lite, lock-on
Brakes SRAM Guide R hydraulic disc
Brake Levers SRAM Guide R hydraulic
Drivetrain 1x
Shifters SRAM GX Eagle, 12-speed
Front Derailleur N/A
Rear Derailleur SRAM GX Eagle, Roller Bearing Clutch
ISCG Tabs ISCG05
Chainguide N/A
Cranks SRAM Descendant 6k Eagle, direct mount
Chainrings SRAM Descendant 6k Eagle, direct mount, 32 tooth, X-Sync
Bottom Bracket PF92
Pedals N/A
Chain SRAM GX Eagle
Cassette SRAM XG-1275, 10-50 tooth, 12-speed
Rims Bontrager Line Comp 30, Tubeless Ready (tubeless strips included, valves sold separately)
Hubs Bontrager Line Comp 30, 54T Rapid Drive, Boost110 front, Boost148 rear
Spokes
Tires Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120tpi, aramid bead, 29" x 2.40"
Saddle Bontrager Evoke 2, chromoly rails
Seatpost Bontrager Drop Line, internal routing
15.5": 100mm travel, 17.5" and 18.5": 125mm travel, 19.5" through 23": 150mm travel
Seatpost Diameter 31.6mm
Seatpost Clamp Standard single bolt
Rear Dropout / Hub Dimensions 148x12mm Boost
Max. Tire Size
Bottle Cage Mounts Yes (single)
Colors Matte Quicksilver
Warranty Lifetime frame, 5 years swing arm, 1 year paint and decals
Weight 31 lb 1.7 oz (14,110 g)
Miscellaneous Full Floater, EVO link suspension
ABP (Active Braking Pivot)
Straight Shot frame design
Knock Block frame defense
Mino Link adjustable geometry
Control Freak internal cable routing
Price $3,199.99
More Info www.trekbikes.com
