2022 Trek Fuel EX 7 Bike
(discontinued)

Discontinued
s1600 photo 178719.jpg?VersionId=J7h0Wjl
c70 photo 178719
c70 photo 499104.jpg?VersionId=Jqbkcg2tt1qIJ. cTR.prmQ037.w
c70 photo 213821
c70 photo 568765
c70 photo 511878
c70 photo 899728
s1600 photo 178719.jpg?VersionId=J7h0Wjl s1600 photo 499104 s1600 photo 213821.jpg?VersionId=LENIvoy.EKn0VN8N0ym8EmEyUI02iK s1600 photo 568765.jpg?VersionId=jye KdEg0Q7z6OPw 7FZL s1600 photo 511878 s1600 photo 899728
Related:
Trek
Where To Buy
$70 standard shipping on bikes (continental U.S. only).
$70 standard shipping on bikes (continental U.S. only).
$2,999.99
Fuel EX 5 Gen 7
$2,999.99
Fuel EX 8 Gen 7
$3,999.99
Fuel+ EX 5 Gen 2
$6,099.99
Fuel+ EX 8 Gen 2
$7,699.99
Free standard UK delivery on orders over £50.
Free standard UK delivery on orders over £50.
£3,200.00
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free U.S. shipping on everything.
International shipping available. Some exclusions apply.
Free shipping on orders over $69 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Trek Fuel EX 7 Bike
Model Year
2022
Intended Use
Trail
Rider
Unisex
Sizes and Geometry
XS 27.5" (high, low)
SM 27.5" (high, low)
MD 29" (high, low)
ML 29" (high, low)
LG 29" (high, low)
XL 29" (high, low)
XXL 29" (high, low)
View Full Geometry
Sizes Additional Info
Geometry adjustable via Mino Link flip chip in rear rocker link pivot.
XS/SM get 27.5" wheels, MD/ML/LG/XL/XXL get 29" wheels.
View Full Geometry
Wheel Size
27.5" (650b)
29"
Frame Material
Aluminum
Frame Material Details
Alpha Platinum Aluminum, magnesium rocker link, molded down tube and chainstay protection
Rear Travel
130mm
Rear Shock
FOX FLOAT Performance, EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab
27.5": 210mm x 52.5mm; 29": 210mm x 55mm
Fork
RockShox 35 Gold RL, Motion Control damper, DebonAir spring, lockout, 44mm offset, Maxle Stealth axle
Fork Travel
140mm
Head Tube Diameter
Tapered, 1.125" top, 1.5" bottom
Headset
Trek Knock Block Integrated, 58° radius, cartridge bearings
Handlebar
Bontrager, alloy, 750mm width, 15mm rise, 31.8mm clamp diameter
Stem
Bontrager Rhythm Comp, 50mm length, 0° rise, 31.8mm bar clamp, Knock Block compatible
Grips
Bontrager XR Trail Comp, nylon lock-on
Brakes
Shimano MT410, 2-piston, Shimano RT56 180mm 6-bolt rotors
Brake Levers
Shimano MT4100
Drivetrain
1x
Shifters
SRAM NX Eagle, 12-speed
Front Derailleur
None
Rear Derailleur
SRAM NX Eagle, 12-speed
ISCG Tabs
ISCG05
Chainguide
None
Cranks
SRAM NX Eagle DUB
Length: 170mm (XS-SM), 175mm (MD-XL)
Chainrings
SRAM NX Eagle, 30 tooth, steel
Bottom Bracket
SRAM DUB, 92mm PressFit
Pedals
None
Chain
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle PG-1230, 12-speed, 11-50 tooth
Rims
Bontrager Line Comp 30 wheelset, tubeless ready
Hubs
Bontrager Line Comp 30 wheelset, 110x15mm Boost front, 148x12mm Boost rear with Rapid Drive 54 freehub and HG driver
Spokes
Bontrager Line Comp 30 wheelset
Tires
Bontrager XR4 Team Issue, tubeless ready, Inner Strength sidewalls, aramid bead, 120 TPI
Saddle
Bontrager Arvada, steel rails, 138mm width
Seatpost
TranzX JD-YSP18 dropper
Drop: 100mm (XS/SM), 150mm (MD/ML/LG/XL/XXL)
Seatpost Diameter
31.6mm
Seatpost Clamp
Single bolt
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
2.6"
Bottle Cage Mounts
One inside front triangle (only on MD and larger sizes)
Colors
Trek Black/Radioactive Red, Dark Prismatic
Warranty
Lifetime frame and wheels; 2 years Trek/Bontrager parts, suspension linkage components, and paint/decals
Weight
31 lb 14.8 oz (14,480 g)
Miscellaneous
• XS/SM get 27.5" wheels, MD/ML/LG/XL/XXL get 29" wheels
• ABP (Active Braking Pivot) rear suspension system
• Geometry adjustable via Mino Link flip chip in rear rocker link pivot
• Straight Shot frame design with Knock Block steerer stop
• Control Freak internal cable routing
• Includes Bontrager TLR rim strips, tubeless valves, and sealant
• Weight given for size MD set up tubeless
Price
$3,329.99
