2021 Transition Spire Carbon XT Bike
(discontinued)

Discontinued
Related:
Where To Buy
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.
Free shipping on orders over $50 (continental U.S. only).
International shipping available. Some exclusions apply.

Specifications

Product
Transition Spire Carbon XT Bike
Model Year
2021
Riding Type
Enduro / All-Mountain
Freeride / Bike Park
Rider
Unisex
Sizes and Geometry
S
M
L
XL
XXL
Wheel Size
29"
Frame Material
Carbon Fiber
Frame Material Details
Full carbon fiber (front triangle, rear triangle, and rocker) made from Japanese Toray fiber with a tailored blend of 24T and 30T materials
Rear Travel
170mm
Rear Shock
FOX FLOAT X2 Factory, 2-position, 205mm x 65mm
Fork
FOX FLOAT 38 GRIP2 Factory, 44mm offset
Fork Travel
170mm
Head Tube Diameter
Straight
Headset
FSA. No.55R/57, 56mm/56mm press-in cups, zero stack
Handlebar
ANVL Mandrel Alloy 35, 800x20mm (S), 800x30mm (M-XL), 800x40mm (XXL)
Stem
ANVL Swage, 40mm
Grips
Sensus Lite
Brakes
Shimano XT M8120 with Shimano RT86 203mm rotors
Brake Levers
Shimano XT M8120
Drivetrain
1x
Shifters
Shimano XT M8100
Front Derailleur
N/A
Rear Derailleur
Shimano XT M8100
ISCG Tabs
ISCG05
Chainguide
OneUp Components Bash Guide
Cranks
Shimano XT M8100, 165mm
Chainrings
30 tooth
Bottom Bracket
73mm BSA threaded
Pedals
N/A
Chain
Shimano XT M8100
Cassette
Shimano XT M8100, 10-51 tooth
Rims
DT Swiss EX 1700 SPLINE 30
Hubs
DT Swiss 350 Straight Pull 36SL
Spokes
DT Swiss Competition
Tires
Front: Schwalbe Magic Mary, Super Trail, Soft, 29"x2.4"
Rear: Schwalbe Big Betty, Super Trail, Soft, 29"x2.4"
Saddle
ANVL Forge Cromo
Seatpost
OneUp Components Dropper
Seatpost Diameter
31.6mm
Seatpost Clamp
37.0mm standard single bolt
Rear Dropout / Hub Dimensions
148x12mm Boost
Max. Tire Size
29"x2.6"
Bottle Cage Mounts
Yes
Colors
Huckleberry, Primer Grey
Warranty
Lifetime
Weight
33 lb 0 oz (14,969 g)
Miscellaneous

Geo adjust chip at the lower shock mount for high and low geometry settings

56mm/56mm press in headset cups are compatible with reach adjust headsets when used with a dual crown fork

Molded rubber frame protection on the downtube, chainstay, and seatstay

Fully guided internal dropper and rear derailleur cable routing in downtube and chainstay, external rear brake cable routing

GiddyUp suspension layout is tuned to work with both air and coil rear shocks

Enduro Max sealed bearings with bearing shields on main pivot

Stock 170mm rear travel with a 65mm stroke shock, optional 160mm rear travel with a 60mm stroke shock

27%-33% suggested sag range

SBG geometry and size-specific chainstays

SRAM UDH derailleur hanger

Accessory mount on underside of top tube

Price
$6,699.00
