2017 Transition Smuggler 2 Bike (discontinued)

Views:
Discontinued
2017 Transition Smuggler 2
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product Transition Smuggler 2 Bike
Model Year 2017
Riding Type Trail
Rider Unisex
Sizes and Geometry
S, M, L, XL View Geometry
Size S M L XL
Top Tube Length 564mm 590mm 619mm 647mm
Head Tube Angle 67.5° 67.5° 67.5° 67.5°
Head Tube Length 100mm 100mm 110mm 120mm
Seat Tube Angle 76° 75.4° 74.9° 74.5°
Seat Tube Length 393mm 419mm 457mm 495mm
Bottom Bracket Height -35mm drop -35mm drop -35mm drop -35mm drop
Chainstay Length 436mm 436mm 436mm 436mm
Wheelbase 1134mm 1160mm 1189mm 1218mm
Standover 677mm 686mm 696mm 709mm
Reach 406mm 432mm 457mm 483mm
Stack 610mm 610mm 620mm 629mm
Wheel Size 29"
Frame Material Aluminum
Frame Material Details Aluminum
Rear Travel 115mm
Rear Shock RockShox Monarch RT3 Debonair, 190mm x 51mm
Fork RockShox Pike RCT3 Solo Air, color match fork decals included
Fork Travel 130mm
Head Tube Diameter Tapered
Headset Cane Creek 40 series, top: 44mm zero stack, bottom: 56mm zero stack
Handlebar Race Face Turbine 35, 760mm x 20mm
Stem Race Face Turbine Basic 35, 50mm length
Grips Velo Single Clamp
Brakes SRAM Guide RSC, SRAM Centerline 180mm rotors
Brake Levers SRAM Guide RSC
Drivetrain 1x
Shifters SRAM X1
Front Derailleur N/A
Rear Derailleur SRAM X01
ISCG Tabs ISCG05, 2.5mm offset
Chainguide N/A
Cranks Race Face Turbine Cinch, 170mm or 175mm
Chainrings Race Face, 30 tooth, direct mount
Bottom Bracket External, 73mm, threaded
Pedals N/A
Chain SRAM PC1130, 11-speed
Cassette SRAM XG1175, 10 - 42 tooth
Rims Stan's Arch MK3 29, 32 hole
Hubs Stan's Neo
Spokes
Tires Front: Maxxis Minion DHF 29x2.3 EXO 3C
Rear: Maxxis Minion DHR II 29x2.3 EXO 3C
Saddle ANVL Forge Stealth CroMo
Seatpost Rockshox Reverb Stealth, 170mm or 125mm length
Seatpost Diameter 31.6mm
Seatpost Clamp quick release
Rear Dropout / Hub Dimensions 12mm x 142mm
Max. Tire Size 29" x 2.3"
Bottle Cage Mounts Yes
Colors Lime green
Stealth black
Warranty 2 years frame
Weight N/A
Miscellaneous Integrated rubber chainstay protection
Collet style main pivot hardware
Internal cable routing with stealth dropper post routing

Complete 2 bike is a build kit that is available with either a 170mm or 125mm dropper post. Kit with 170mm dropper posts come with 175mm cranks. Kit with 125mm dropper post come with 170mm cranks.
Price $4,999
More Info

www.transitionbikes.com
