2014 Specialized Epic S-Works Bike (discontinued)

Views:
Discontinued
Bike - Specialized S-Works Epic - Gloss Red:Silver:Black
2014 Specialized Epic S-Works Bike 2014 Specialized Epic S-Works Bike
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product Specialized Epic S-Works Bike
Model Year 2014
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
S, M, L, XL View Geometry
Size S M L XL
Top Tube Length 22.2 23.3 24.4 25.5
Head Tube Angle 70.5° 70.5° 70.5° 70.5°
Head Tube Length 3.5 4.1 4.7 5.5
Seat Tube Angle 73.75° 73.75° 73.75° 73.75°
Seat Tube Length 15.7 17.1 18.5 20.5
Bottom Bracket Height 13.1 13.1 13.1 13.1
Chainstay Length 17.6 17.6 17.6 17.6
Wheelbase 42.6 43.8 44.9 46.0
Standover 30.3 30.5 30.7 31.2
Reach 15.5 16.5 17.4 18.2
Stack 23.1 23.7 24.2 25.0
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details FACT 11m Carbon Front Triangle, Full FACT Carbon Rear Triangle
Rear Travel 100mm
Rear Shock FOX/Specialized Remote Mini-Brain with AUTOSAG, Kashima Coating, Inertia Valve with Kevlar Hose, Brain Fade Adjust, 205x53mm
Fork RockShox SID World Cup 29 Brain, Inertia Valve Damper, Solo Air Spring, Tapered Carbon Crown/Steerer, Top-Mount Brain Fade and Rebound Adjust, 15mm Thru-Axle
Fork Travel 100mm
Head Tube Diameter Tapered
Headset 1-1/8" and 1-1/2" Threadless, Campy Style Upper with 1-1/2" Lower, Cartridge Bearings
Handlebar S-Works XC, Flat Bar, Carbon, 700mm Wide, 8° Backsweep, 31.8mm
Stem Syntace F109, 6° Rise, 31.8mm Clamp
Grips Specialized Sip Grip, Light Lock-On, Half-Waffle Aramid-Infused, S/M: Regular, Others: XL Thickness
Brakes Shimano XTR Hydraulic Disc, Post Mount, Ti/Metal Pad, Ice Tech, 160mm Rotors
Brake Levers Shimano XTR 985 Hydraulic, with I-Spec Clamps
Drivetrain
Shifters Shimano XTR, 10-Speed
Front Derailleur Shimano XTR M986, Direct Mount, Down-Swing, Dual-Pull
Rear Derailleur Shimano Shadow Plus XTR, 10-Speed, GS Mid Cage
ISCG Tabs N/A
Chainguide N/A
Cranks S-Works OS Carbon, Integrated 1-Piece Spider, 10-Speed XC Double, SRAM Rings, S: 170mm, Others: 175mm
Chainrings
Bottom Bracket PF30, OS Press-In Bearings, Sealed Cartridge
Pedals N/A
Chain Shimano XTR 981
Cassette Shimano XTR M980, 10-Speed, 11-36 Tooth
Rims Roval Control SL 29, Carbon Disc, 22mm Internal Width, 24 Hole Front / 28 Hole Rear
Hubs Roval Control SL 29, Alloy Hub Body with Labyrinth Seal Design, 15mm Thru-Axle, 24 Hole Front // Roval Control SL 29 142+, DT Swiss Star Ratchet, 12mm Thru-Axle, 28 Hole Rear
Spokes DT Swiss Revolution, 2.0/1.5/2.0mm Stainless
Tires S-Works Fast Trak, 2Bliss Ready, 29"x2.0", Foldable Aramid Bead, 120 TPI
Saddle Body Geometry Phenom Expert, Hollow Ti Rails, 143mm
Seatpost Specialized Carbon, Single Bolt, S: 350mm, Others: 400mm
Seatpost Diameter 30.9mm
Seatpost Clamp Specialized 7050 Hard Anodized Alloy, Single Bolt, 31.8mm
Rear Dropout / Hub Dimensions 142+ Dropout x 12mm Thru-Axle
Max. Tire Size
Bottle Cage Mounts Yes
Colors Gloss Carbon/White/Red, or Gloss Red/Silver/Black
Warranty Lifetime Frame Subject to Exclusions // 1 Year: Suspension Attachment Points, Suspension Related Equipment (Including Pivot Points, Bushings, Shock Units, Front Suspension Forks, Chain Stays and Seat Stays, Shock Links, Fasteners) // 5 Years: Chain Stays and Seat Stays
Weight N/A
Miscellaneous SWAT MTB XC Kit with Bottle Cages, EMT Tool, and Top Cap Chain Tool
Price $10,500
More Info Specialized Website
