2020 Specialized Fuse 27.5 Bike

Views:
2020 Specialized Fuse 27.5 - Gloss Crimson
2020 Specialized Fuse 27.5 Bike 2020 Specialized Fuse 27.5 Bike
Create New Tag

Compare to other Bikes

Need more info? View our Trail Mountain Bikes buyer's guide.

Specifications

Product Specialized Fuse 27.5 Bike
Model Year 2020
Riding Type Trail
Rider Unisex
Sizes and Geometry
XS, S, M, L, XL View Geometry
Size XS S M L XL
Top Tube Length 573mm 593mm 613mm 637mm 661mm
Head Tube Angle 66° 66° 66° 66° 66°
Head Tube Length 105mm 105mm 105mm 120mm 135mm
Seat Tube Angle 74° 74° 74° 74° 74°
Seat Tube Length 340mm 375mm 410mm 455mm 505mm
Bottom Bracket Height 315mm 315mm 315mm 315mm 315mm
Chainstay Length 430mm 430mm 430mm 430mm 430mm
Wheelbase 1120mm 1140mm 1160mm 1186mm 1213mm
Standover 717mm 736mm 739mm 744mm 789mm
Reach 400mm 420mm 440mm 460mm 480mm
Stack 603mm 603mm 603mm 615mm 630mm
Wheel Size 27.5+
Frame Material Aluminum
Frame Material Details A1 Aluminum
Rear Travel Hardtail
Rear Shock N/A
Fork RockShox Judy Silver TK
Fork Travel 130mm
Head Tube Diameter Tapered
Headset N/A
Handlebar Specialized Stout Riser, 9-degree backsweep, 5-degree upsweep, 15mm rise, 750/780mm width, 31.8mm bore
Stem Specialized Stout, 6-degree rise, 45mm length
Grips Specialized Trail Grips
Brakes Tektro HD-M275 with Tektro rotors, 180mm front, 160mm rear
Brake Levers Tektro HD-M275
Drivetrain 1x
Shifters Shimano Deore, 10-speed
Front Derailleur N/A
Rear Derailleur Shimano Deore, 10-speed
ISCG Tabs No
Chainguide N/A
Cranks Specialized Stout, forged alloy
Chainrings 30 tooth
Bottom Bracket Square taper, 73mm
Pedals Specialized Dirt
Chain KMC X10, 10-speed
Cassette SunRace, 10-speed, 11-42 tooth
Rims Specialized alloy, disc-only, double-wall, 29mm internal width, 28h
Hubs Specialized, sealed cartridge bearings
Spokes Stainless, 14g
Tires Specialized Butcher, GRID Trail, Gripton compound, 2Bliss Ready, 27.5x2.8"
Saddle Specialized Bridge Comp, hollow cr-mo rails, 155/143mm
Seatpost TranzX dropper, XS/S: 100mm travel, M: 120mm travel, L/XL: 150mm travel
Seatpost Diameter 34.9mm
Seatpost Clamp Specialized alloy single bolt, 38.6mm
Rear Dropout / Hub Dimensions 12mm x 148mm
Max. Tire Size
Bottle Cage Mounts Yes (downtube and seat tube)
Colors Gloss Crimson/Rocket Red or Satin Sage Green/Black
Warranty Limited lifetime frame warranty
Weight N/A
Miscellaneous Internal cable routing
Price $1,250
