| Product |
Specialized Big Hit 1 Bike |
| Model Year |
|
| Riding Type |
Freeride / Bike Park, Downhill
|
| Rider |
Unisex
|
| Sizes and Geometry |
| Size |
S
|
M
|
L
|
| Top Tube Length |
537mm
|
554mm
|
576mm
|
| Head Tube Angle |
65.5°
|
65.5°
|
65.5°
|
| Head Tube Length |
120mm
|
120mm
|
120mm
|
| Seat Tube Angle |
71-deg
|
71-deg
|
71-deg
|
| Seat Tube Length |
394mm
|
419mm
|
458mm
|
| Bottom Bracket Height |
365mm
|
365mm
|
365mm
|
| Chainstay Length |
426mm
|
426mm
|
426mm
|
| Wheelbase |
1162mm
|
1185mm
|
1207mm
|
| Standover |
758m
|
769mm
|
770mm
|
| Reach |
404mm
|
427mm
|
449mm
|
| Stack |
595mm
|
595mm
|
595mm
|
|
| Wheel Size |
|
| Frame Material |
Other
|
| Frame Material Details |
M4 tubing ORE TT/DT, tapered HT
|
| Rear Travel |
190.5mm
|
| Rear Shock |
Custom X-Fusion Vector R, coil over w/piggy back, adj. rebound, Spring rate S: 400, M: 450, L: 500 8.5x2.5
|
| Fork |
X-Fusion Vengeance, coil spring, tapered alloy steerer, reb adj., 20mm thru-axle
|
| Fork Travel |
170mm
|
| Head Tube Diameter |
Tapered 1 1/8 to 1.5-inch
|
| Headset |
1-1/8" loose cage upper bearing and 1.5" alloy lower loose-cage bearing
|
| Handlebar |
Specialized DH low-rise bar, 6061 alloy, 750mm wide, 8 degree backsweep, 6 degree up, 31.8mm
|
| Stem |
Specialized DH, forged, 35mm length, 4-bolt, 31.8mm
|
| Grips |
Specialized lock-on, S/M: Grappler, Other: Rocca
|
| Brakes |
Avid Juicy 3, hydraulic disc, metallic pads, G3 Clean Sweep rotor, 203mm and 185mm rotors
|
| Brake Levers |
Avid Juicy 3 hydraulic
|
| Drivetrain |
1x
|
| Shifters |
SRAM X.4, 8-speed, trigger, rear only
|
| Front Derailleur |
N/A
|
| Rear Derailleur |
SRAM X.7, 9-speed, short cage
|
| ISCG Tabs |
YES
|
| Chainguide |
SBC Chain Guide
|
| Cranks |
Truvativ Ruktion, 170mm
|
| Chainrings |
34t steel, 4-bolt, compact 104mm pattern
|
| Bottom Bracket |
Truvativ Howitzer XR, oversize sealed outboard cartridge bearing, 73mm shell
|
| Pedals |
Alloy platform, 9/16"
|
| Chain |
KMC X8, 8-speed, w/ reuseable Missing Link
|
| Cassette |
SRAM PG-830, 8-speed, 11-32t
|
| Rims |
P-Disc, 32mm, 36h
|
| Hubs |
Front: Specialized Hi Lo disc, laser-etched logo, sealed cartridge bearing, 20mm thru-axle, 36h. Rear: Specialized Disc, bolt-on 135mm, 36h
|
| Spokes |
2.0mm (14g) stainless
|
| Tires |
Specialized Butcher SX, 60 TPI, aramid bead, soft dual compound, 26x2.3"
|
| Saddle |
Specialized Demo, 7mm hollow Cr-Mo rails
|
| Seatpost |
6061 alloy, two bolt micro adjust, no offset, 300mm
|
| Seatpost Diameter |
30.9mm
|
| Seatpost Clamp |
Alloy collar w/ QR, black
|
| Rear Dropout / Hub Dimensions |
N/A
|
| Max. Tire Size |
2.5
|
| Bottle Cage Mounts |
NO
|
| Colors |
Green/Blakc
|
| Warranty |
Limited Lifetime Warranty
|
| Weight |
N/A
|
| Miscellaneous |
|
| Price |
$2,100
|
| More Info |
Specialized website
|
