2015 Santa Cruz Tallboy Carbon R (discontinued)

Views:
Discontinued
2015 Santa Cruz Tallboy Carbon R bike - white
2015 Santa Cruz Tallboy Carbon R 2015 Santa Cruz Tallboy Carbon R
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes buyer's guide.

Specifications

Product Santa Cruz Tallboy Carbon R
Model Year 2015
Riding Type Cross Country
Rider Unisex
Sizes and Geometry
S, M, L, XL, XXL View Geometry
Size S M L XL XXL
Top Tube Length 21.9" 23.12" 24.12" 25.12" 26.02"
Head Tube Angle 70.2° 70.2° 70.2° 70.2° 70.2°
Head Tube Length 3.54" 3.94" 3.94" 4.33" 4.72"
Seat Tube Angle 72.3° 72.4° 72.4° 72.4° 72.4°
Seat Tube Length 16.5" 17.5" 18.5" 20" 21.5"
Bottom Bracket Height 13.04" 13.04" 13.04" 13.04" 13.04"
Chainstay Length 17.53" 17.53" 17.53" 17.53" 17.53"
Wheelbase 41.72" 42.98" 43.98" 45" 45.91"
Standover 28.15" 28.54" 29" 29.55" 30.19"
Reach 14.22" 15.36" 16.37" 17.26" 18.05"
Stack 24.02" 24.4" 24.41" 24.79" 25.17"
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details 29" Full Carbon
Rear Travel 100mm
Rear Shock FOX Float CTD Evolution (FOX Float CTD Adjust Factory Kashima Option)
Fork RockShox Recon Gold TK Solo Air with 15mm Through Axle and Tapered Steerer
Fork Travel 120mm
Head Tube Diameter Mixed Taper 1.5" Lower, 1-1/8" Upper
Headset Cane Creek 10 Series Tapered, Cartridge Bearing
Handlebar Race Face Evolve Flat , 31.8mm x 720mm
Stem Race Face Ride
Grips Santa Cruz Palmdale Lock-On
Brakes Shimano Deore M615 with Shimano RT66 160mm Rotors
Brake Levers Shimano
Drivetrain 2x
Shifters Shimano Deore M610
Front Derailleur Shimano Deore
Rear Derailleur Shimano XT M786 GS Shadow Plus
ISCG Tabs ISCG 05
Chainguide N/A
Cranks Shimano Deore M615 2x10-Speed
Chainrings 24/38 Tooth
Bottom Bracket Included with Crankset, Standard 73mm Threaded
Pedals N/A
Chain Shimano SLX HG75
Cassette Shimano SLX HG81, 10-Speed, 11-36 Tooth
Rims WTB STi19 TCS
Hubs SRAM MTH 716 Front / SRAM MTH 746 Rear
Spokes DT Champion 2.0
Tires Maxxis Ikon, 29"x2.2", Tubeless Ready
Saddle WTB Volt Race
Seatpost Race Face Ride, 375mm
Seatpost Diameter 30.9mm
Seatpost Clamp Standard
Rear Dropout / Hub Dimensions 142mm x 12mm Through-Axle, Includes a DT RWS Axle
Max. Tire Size 29" x 2.35"
Bottle Cage Mounts Yes
Colors White and Burgundy, Satin Black and Aqua Blue
Warranty Five Year Frame, Lifetime Bearing
Weight N/A
Miscellaneous Fork Compatibility: 100-120mm
Price $3,399
