2016 Santa Cruz Tallboy Carbon C R Bike (discontinued)

Views:
Discontinued
MY16_TallboyC_R_Red
2016 Santa Cruz Tallboy Carbon C R Bike 2016 Santa Cruz Tallboy Carbon C R Bike
Create New Tag

Compare to other Bikes

Need more info? View our Cross Country Mountain Bikes or Trail Mountain Bikes buyer's guides.

Specifications

Product Santa Cruz Tallboy Carbon C R Bike
Model Year 2016
Riding Type Cross Country, Trail
Rider Unisex
Sizes and Geometry
S, M, L, XL, XXL View Geometry
Size S M L XL XXL
Top Tube Length 21.81" 23.12" 24.12" 25.12" 26.02"
Head Tube Angle 70.2° 70.2° 70.2° 70.2° 70.2°
Head Tube Length 3.54" 3.94" 3.94" 4.33" 4.72"
Seat Tube Angle 72.3° 72.4° 72.4° 72.4° 72.4°
Seat Tube Length 16.5" 17.5" 18.5" 20" 21.5"
Bottom Bracket Height 13.04" 13.04" 13.04" 13.04" 13.04"
Chainstay Length 17.53" 17.53" 17.53" 17.53" 17.53"
Wheelbase 41.72" 42.98" 43.98" 45" 45.91"
Standover 28.15" 28.54" 29" 29.55" 30.19"
Reach 14.22" 15.36" 16.37" 17.26" 18.05"
Stack 24.02" 24.4" 24.41" 24.79" 25.17"
Wheel Size 29"
Frame Material Carbon Fiber
Frame Material Details Carbon C
Rear Travel 100mm
Rear Shock Fox Float Performance
Fork Rockshox Recon Gold TK 120mm Solo Air w/15mm through axle and tapered steerer
Fork Travel 120mm
Head Tube Diameter mixed taper 1.5" Lower, 1'1/8" upper
Headset Cane Creek 10 series tapered, cartridge bearing
Handlebar Race Face Evolve Flat 720, 31.8mm clamp
Stem Race Face Ride
Grips Santa Cruz Palmdale Lock-on
Brakes Shimano Deore M615 w/Shimano RT66; 160mm
Brake Levers
Drivetrain 2x
Shifters Shimano SLX M670
Front Derailleur Shimano M618
Rear Derailleur Shimano XT M786 GS Shadow Plus
ISCG Tabs ISCG-05
Chainguide
Cranks Shimano Deore M617
Chainrings 22/36t
Bottom Bracket Included w/ crankset, Standard, Threaded
Pedals
Chain KMC X10.93, 10sp
Cassette Shimano SLX HG81, 10sp, 11-36
Rims WTB STi19 TCS
Hubs F Sram MTH 716 15x100, R Sram MTH 746 142x12
Spokes DT Swiss Champion
Tires Maxxis Ikon 29x2.2, Tubeless Ready
Saddle WTB Volt Race
Seatpost Race Face Ride, 30.9x375mm
Seatpost Diameter 30.9mm
Seatpost Clamp
Rear Dropout / Hub Dimensions 142x12
Max. Tire Size 2.35"
Bottle Cage Mounts 2x bottle cage mounts
Colors Red & White, Matte Black & Yellow
Warranty Lifetime frame, Lifetime bearing
Weight 27 lb 9.3 oz (12,510 g)
Miscellaneous
Price $3,399
