2019 Santa Cruz Bronson R Bike (discontinued)

Bronson Aluminum R Primer Grey and Silver
2019 Santa Cruz Bronson R Bike 2019 Santa Cruz Bronson R Bike 2019 Santa Cruz Bronson R Bike 2019 Santa Cruz Bronson R Bike
Create New Tag

Compare to other Bikes

Need more info? View our Enduro / All-Mountain Mountain Bikes buyer's guide.


Product Santa Cruz Bronson R Bike
Model Year 2019
Riding Type Enduro / All-Mountain
Rider Unisex
Sizes and Geometry
XS (High, Low), S (High, Low), M (High, Low), L (High, Low), XL (High, Low) View Geometry
Size XS (High, Low) S (High, Low) M (High, Low) L (High, Low) XL (High, Low)
Top Tube Length 541mm 574mm 598mm 621mm 656mm
Head Tube Angle 65.4°, 65.1° 65.4°, 65.1° 65.4°, 65.1° 65.4°, 65.1° 65.4°, 65.1°
Head Tube Length 100mm 110mm 120mm 130mm 145mm
Seat Tube Angle 75.3°, 75° 75.3°, 75° 75.3°, 75° 75.3°, 75° 75.3°, 75°
Seat Tube Length 370mm 380mm 405mm 430mm 460mm
Bottom Bracket Height 344mm, 340mm 344mm, 340mm 344mm, 340mm 344mm, 340mm 344mm, 340mm
Chainstay Length 430mm 430mm 430mm 430mm 430mm
Wheelbase 1134mm 1167mm 1191mm 1215mm 1252mm
Standover 694mm, 692mm 704mm, 700mm 721mm, 717mm 721mm, 715mm 720mm, 715mm
Reach 389mm, 385mm 419mm, 415mm 436mm, 429mm 459mm, 455mm 489mm, 485mm
Stack 584mm, 586mm 593mm, 595mm 602mm, 605mm 611mm, 614mm 625mm, 627mm
Wheel Size 27.5" (650b), 27.5+
Frame Material Aluminum
Frame Material Details Internal cable routing with chainstay protection
Rear Travel 150mm
Rear Shock RockShox Super Deluxe R
Fork RockShox Yari Motion Control RC
Fork Travel 160mm
Head Tube Diameter Tapered
Headset Cane Creek 10 IS Integrated
Handlebar Race Face Aeffect R
Stem Race Face Ride, 50mm length
Grips Santa Cruz Palmdale
Brakes SRAM Guide T with Avid Centerline 200mm front/180mm rear rotors
Brake Levers SRAM Guide T
Drivetrain 1x
Shifters SRAM NX Eagle, 12-speed
Front Derailleur N/A
Rear Derailleur SRAM NX Eagle
Cranks SRAM NX Eagle 148 DUB, 170mm (XS-S), 175mm (M-XL)
Chainrings 32 tooth
Bottom Bracket 73mm threaded
Pedals None included
Chain SRAM NX Eagle
Cassette SRAM PG1230, 11-50 tooth, 12-speed
Rims WTB ST i29 TCS 2.0, 32 hole
Plus Size Option: WTB ST i35 TCS 2.0
Hubs Front: SRAM MTH 716, 15mm x 110mm, torque cap
Rear: SRAM MTH 746, 12mm x 148mm
Spokes DT Swiss Competition
Tires Front: Maxxis Minion, 2.5" DHF 3C EXO TR
Rear: Maxxis Minion, 2.4" DHR II EXO TR
Plus Size Option
Front: Maxxis Minion DHF, 2.6" DC EXO TR
Rear: Maxxis Minion DHR II, 2.6" 3C EXO TR
Saddle WTB Silverado Race
Seatpost Race Face Aeffect
Seatpost Diameter 31.6mm
Seatpost Clamp Standard single bolt
Rear Dropout / Hub Dimensions Boost, 12mm x 148mm
Max. Tire Size 2.8"
Bottle Cage Mounts Yes
Colors Industry Blue/Gold
Primer Grey/Silver
Warranty Lifetime frame and bearings
Weight 33 lb 15.9 oz (15,420 g)
Miscellaneous Fork compatibility: 150mm-170mm
Internal cable routing
Not front derailleur compatible
Price $3,499
